FRONT WHEEL (SEE NOTE) MODEL V F.NO.124025%,MODEL X/Y

SWINGARM FOR SUZUKI FB 100 1986

CHAIN GUARD

Item numbers

SWINGING ARM ASSY, REAR (RED)

61000-09421-00J 610000942100J

Not available

SWINGING ARM ASSY, REAR (BLUE)

61000-09421-04Y 610000942104Y

Not available

SWINGING ARM ASSY, REAR (BLUE)

61000-09421-0NF 61000094210NF

Not available

SWINGING ARM ASSY, REAR (RED)

61000-09421-19A 610000942119A

Not available

SWINGING ARM ASSY, REAR (BLUE)

61000-09421-1UY 61000094211UY

Not available

SWINGING ARM ASSY, REAR (MAROON)

61000-09421-20F 610000942120F

Not available

SWINGING ARM ASSY, REAR (MAROON)

61000-09421-24D 610000942124D

Not available

SWINGING ARM ASSY, REAR (GREEN)

61000-09421-Y98 6100009421Y98

Not available

SWINGING ARM ASSY, REAR (BLUE)

61000-09470-1UY 61000094701UY

Not available

SWINGING ARM ASSY, REAR (MAROON)

61000-09470-20F 610000947020F

Not available

PIVOT BUSH
BUSH, RH (10X23X35)

09319-10009-000 0931910009000

$10,97

Unit Price

BUSHING, 10X23X30
BUSH, LH (10X23X30)

09319-10043-000 0931910043000

$23,97

Unit Price

SHAFT, PIVOT

61211-09420-000 6121109420000

Not available

WASHER

08322-01107-000 0832201107000

$2,97

Unit Price

WASHER, 10.2X18.5X1.8
LOCK WASHER

09162-10008-000 0916210008000

$5,97

Unit Price

NUT

08310-00107-000 0831000107000

$3,97

Unit Price

CUSHION

09320-22001-000 0932022001000

Not available

CAP

09250-22002-000 0925022002000

$3,97

Unit Price

TORQUE LINK, REAR

64311-09401-000 6431109401000

Not available

BOLT (8X29)

09111-08016-000 0911108016000

Not available

CUSHION, REAR (10X26X2)

64322-09401-000 6432209401000

Not available

08322-0108A
WASHER

08322-01083-000

Not available

WASHER, CHAIN ADJUSTE
LOCK WASHER

09162-08008-000 0916208008000

$3,97

Unit Price

NUT 8MM
NUT

09140-08008-000 0914008008000

$2,97

Unit Price

04111-20208-000

04111-2020A-000

$2,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SWINGARM of your Suzuki of FB. Let us know if you have any questions.
