TAIL LIGHT ASSY (GSX-R1000AUFL5 E21)

WIRING HARNESS (GSX-R1000AL5 E21) FOR SUZUKI GSX-R 1000 2015

WIRING HARNESS (GSX-R1000AUFL5 E21)

Item numbers
WIRING HARNESS (GSX-R1000AL5 E21) Suzuki MOTO 1000 GSX-R 2015 GSX-R1000AUF L5
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
1
HARNESS, WIRING NO.1

36610-47HD0-000   3661047HD0000

3661047HD0000
Not available
2
.FUSE (10A)
.FUSE (10A)

09481-10501-000  

0948110501000
Not available
3
.FUSE (15A)

09481-15501-000   0948115501000

0948115501000

Unit Price

4
FUSE, 30A

09481-30501-000  

09481-30504-000
 0948130501000

Unit Price

5
DISCONTINUE
HARNESS, WIRING NO.2

36620-47H20-000  

3662047H20000
Not available
6
.COVER, CONNECTOR

36618-47H00-000   3661847H00000

3661847H00000

Unit Price

7
CAP, TS

36654-06J20-000  

36654-06J21-000
 3665406J20000

Unit Price

8
DISCONTINUE
WIRE, REARCOMBINATION

36855-47H00-000  

3685547H00000
Not available
9
CLAMP

09403-06322-000  

09403-06328-000
 0940306322000

Unit Price

10
CLAMP(L:65)
CLAMP(L:65)

09404-06429-000  

09404-06039-000
 0940406429000

Unit Price

11
BAND,WIRING HARNESS<br />CLAMP (L:125)
BAND, WIRING HARNESS
CLAMP (L:125)

09407-14403-000   0940714403000

0940714403000

Unit Price

12
BAND, WIRING HARNESS

09407-11401-000  

09407-14403-000
 0940711401000

Unit Price

13
CLAMP,WIRING HARNESS<br />CLAMP (L:165)
CLAMP, WIRING HARNESS
CLAMP (L:165)

09407-18402-000   0940718402000

0940718402000

Unit Price

14
CLAMP

09407-19401-000  

09407-22403-000
 0940719401000

Unit Price

15
CLAMP

09407-19401-000  

09407-22403-000
 0940719401000

Unit Price

16
CLAMP

09408-00242-000   0940800242000

0940800242000

Unit Price

17
BOLT

01547-0612A-000   015470612A000

015470612A000

Unit Price

18
WIRE, OIL PRESSURE SWITCH LEAD
WIRE, OIL PRESSURE SWITCH

36851-47H01-000   3685147H01000

3685147H01000

Unit Price

19
DISCONTINUE
WIRE, RELAY LEAD

36857-47H00-000  

3685747H00000
Not available
20
DISCONTINUE
WIRE, ISC LEAD

36859-47H10-000  

3685947H10000
Not available
21
LOCK SET

37101-14880-000   3710114880000

3710114880000
Not available
22
.LOCK ASSY, STEERING

37100-14J30-000   3710014J30000

3710014J30000
Not available
23
BOLT, STEERING LOCK

09119-08100-000  

37152-17K00-000
 0911908100000

Unit Price

24
SWITCH ASSY, STOP LAMP
SWITCH ASSY, STOP LAMP

37740-31D00-000   3774031D00000

3774031D00000

Unit Price

25
SPRING

09443-06087-000   0944306087000

0944306087000

Unit Price

26
HOSE
HOSE

09352-50823-600  

09352-50005-600
 0935250823600

Unit Price

27
SWITCH ASSY, SIDE STAND

37840-47H00-000  

37840-47H01-000
 3784047H00000

Unit Price

28
BOLT (6X20)
BOLT (6X20)

09103-06286-000   0910306286000

0910306286000

Unit Price

29
HORN ASSY

38500-47H00-000   3850047H00000

3850047H00000

Unit Price

30
BOLT
BOLT

01550-0616B-000   015500616B000

015500616B000

Unit Price

31
RELAY ASSY<br />RELAY ASSY, FUEL PUMP
RELAY ASSY
RELAY ASSY, FUEL PUMP

38740-24X50-000   3874024X50000

3874024X50000

Unit Price

32
RELAY ASSY<br />RELAY ASSY, FAN MOTOR
RELAY ASSY
RELAY ASSY, FAN MOTOR

38740-24X50-000   3874024X50000

3874024X50000

Unit Price

33
KEY, BLANK(IMMOBII)
KEY, BLANK

37146-41G00-000   3714641G00000

3714641G00000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
