TRANSMISSION

GEAR SHIFTING ASSY FOR SUZUKI GSX-R 1000 2017

FUEL EVAP SYSTEM

Item numbers
GEAR SHIFTING ASSY Suzuki MOTO 1000 GSX-R 2017 GSX-R1000RL7 / GSX-R1000RZL7 E21
1
1
2
3
3
4
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
23
24
25
26
26
27
28
29
30
31
32
33
34
35
36
36
37
38
39
40
41
42
43
44
45
1
FORK, GEAR SHIFT NO.1

25211-01H11-000   2521101H11000

2521101H11000

Unit Price

2
FORK, GEAR SHIFT NO.3

25231-01H02-000   2523101H02000

2523101H02000

Unit Price

3
SHAFT, GEAR SHIFT FORK(L:152)
SHAFT, GEAR SHIFT FORK

25411-38B01-000   2541138B01000

2541138B01000

Unit Price

4
SCREW (6X12)

09136-06147-000   0913606147000

0913606147000

Unit Price

5
CAM COMP, GEAR SHIFT
CAM, GEAR SHIFT

25310-17K00-000   2531017K00000

2531017K00000

Unit Price

6
BOLT, GEAR SHIFT CAM PLATE

25312-17K00-000   2531217K00000

2531217K00000

Unit Price

7
PLATE, GEAR SHIFT CAM

25381-17K00-000   2538117K00000

2538117K00000

Unit Price

8
SCREW (6X12)

09136-06147-000   0913606147000

0913606147000

Unit Price

9
BEARING, ROLLER KOYO<br />BEARING (25X47X8)
BEARING, ROLLER KOYO
BEARING (25X47X8)

09262-25006-000   0926225006000

0926225006000

Unit Price

10
R BEARING 25X32X12<br />BEARING (25X32X12)
R BEARING 25X32X12
BEARING (25X32X12)

09263-25018-000   0926325018000

0926325018000

Unit Price

11
25350-06G10
STOPPER, SHIFT CAM

25350-06G00-000   2535006G00000

2535006G00000
Not available
12
SPRING, GEAR SHIFT CAM STOPPER

25355-17K00-000   2535517K00000

2535517K00000

Unit Price

13
BOLT<br />BOLT (6X14.3)
BOLT
BOLT (6X14.3)

09111-06041-000   0911106041000

0911106041000

Unit Price

14
THRUST WASHER<br />WASHER
THRUST WASHER
WASHER

08211-06141-000   0821106141000

0821106141000

Unit Price

15
SHAFT COMP, GEAR SHIFT
SHAFT, GEAR SHIFT

25510-17K00-000   2551017K00000

2551017K00000

Unit Price

16
PLATE, GEAR SHIFT CAM DRIVE

25512-06G20-000   2551206G20000

2551206G20000

Unit Price

17
SPRING, GEAR SHIFT PLATE RETURN
SPRING, GEAR SHIFT PLATE

25518-01H00-000   2551801H00000

2551801H00000

Unit Price

18
WASHER, GEAR SHIFT SHAFT END
WASHER, GEAR SHIFT SHAF END

25519-01H00-000   2551901H00000

2551901H00000

Unit Price

19
STOPPER, GEAR SHIFT ARM
STOPPER, GEAR SHIFT ARM

25671-01011-000   2567101011000

2567101011000

Unit Price

20
SCREW
SCREW (6X16)

09126-06014-000   0912606014000

0912606014000

Unit Price

21
WASHER (14X29X0.8)
WASHER (14X29X0.8)

09160-14016-000   0916014016000

0916014016000

Unit Price

22
SHIM (14X24X1)

09181-14195-000   0918114195000

0918114195000

Unit Price

23
BEARING, RR CUSHION<br />BEARING (14X20X12)
BEARING, RR CUSHION
BEARING (14X20X12)

09263-14027-000   0926314027000

0926314027000

Unit Price

24
SEAL, OIL(14X22X7.3)
OIL SEAL (14X22X7.3)

09283-14005-000   0928314005000

0928314005000

Unit Price

25
SPRING
SPRING

09444-20001-000   0944420001000

0944420001000

Unit Price

26
CIRCLIP
CIRCLIP

08331-3114A-000   083313114A000

083313114A000

Unit Price

27
ARM COMP, GEAR SHIFT LINK

25520-17K00-000  

25520-17K10-000
 2552017K00000

Unit Price

28
ROD, GEAR SHIFT LINK

25525-17K10-000   2552517K10000

2552517K10000

Unit Price

29
LEVER ASSY, GEAR SHIFT

25600-17K00-000   2560017K00000

2560017K00000

Unit Price

30
.RUBBER, GEAR SHIFT PEDAL
.RUBBER, GEAR SHIFT PEDAL

25652-20C00-000   2565220C00000

2565220C00000

Unit Price

31
SEAL, GEAR SHIFT LEVER
.OIL SEAL (18X24X3.5)

09284-18005-000   0928418005000

0928418005000

Unit Price

32
BOLT, FR FOOTREST BRK
BOLT (8X20)

09106-08167-000   0910608167000

0910608167000

Unit Price

33
NUT
NUT

09140-06025-000   0914006025000

0914006025000

Unit Price

34
WASHER (10X30X2.5)

09160-10144-000   0916010144000

0916010144000

Unit Price

35
BOLT
BOLT

07120-0625A-000   071200625A000

071200625A000

Unit Price

36
NUT

09140-06020-000   0914006020000

0914006020000

Unit Price

37
SHAFT, GEAR SHIFT LEVER

25617-17K00-000   2561717K00000

2561717K00000

Unit Price

38
BRACKET, GEAR SHIFT LEVER

25681-17K00-000   2568117K00000

2568117K00000

Unit Price

39
WASHER, GEAR SHIFT LEVER LH

25619-17K00-000   2561917K00000

2561917K00000

Unit Price

40
SENSOR ASSY, GEAR POSITION

37730-17K00-000   3773017K00000

3773017K00000

Unit Price

41
BOLT
BOLT (5X16)

09106-05023-000   0910605023000

0910605023000

Unit Price

42
O RING<br />O RING (D:2.4,ID:26.2)
O RING
O RING (D:2.4, ID:26.2)

09280-26005-000   0928026005000

0928026005000
Not available
43
CLAMP(L:65)
CLAMP(L:65)

09404-06429-000  

09404-06039-000
 0940406429000

Unit Price

44
SENSOR & ROD SET

25501-17810-000  

25501-17811-000
 2550117810000

Unit Price

45
CLAMP<br />CLAMP (L:145)
CLAMP
CLAMP (L:145)

09407-14407-000   0940714407000

0940714407000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
