FUEL TANK (MODEL K4) REFER TO FIG.38C(H-13) FOR MODEL K5

FUEL TANK (MODEL K5) FOR SUZUKI SV 1000 2004

FAIRING

Item numbers
FUEL TANK (MODEL K5) Suzuki MOTO 1000 SV 2004 SV1000S1K4(E2)
1
1
1
1
1
1
1A
1B
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
1
44100-16G61-YAY
TANK ASSY, FUEL (BLACK)

44100-16G60-YAY  

4410016G60YAY
Not available
1
TANK ASSY, FUEL (SILVER)

44100-16G60-YD8   4410016G60YD8

4410016G60YD8
Not available
1
DISCONTINUE
TANK ASSY, FUEL (RED)

44100-16G60-YU7   4410016G60YU7

4410016G60YU7
Not available
1
TANK ASSY, FUEL (BLACK)

44100-16G70-YAY   4410016G70YAY

4410016G70YAY
Not available
1
TANK ASSY, FUEL (SILVER)

44100-16G70-YD8   4410016G70YD8

4410016G70YD8
Not available
1
TANK ASSY, FUEL (RED)

44100-16G70-YU7   4410016G70YU7

4410016G70YU7
Not available
1A
TANK ASSY, FUEL

44100-16GB0-LR5   4410016GB0LR5

4410016GB0LR5
Not available
1B
TAPE SET

68110-16GA0-LR5   6811016GA0LR5

6811016GA0LR5
Not available
2
EMBLEM, S
EMBLEM

68111-18G20-000   6811118G20000

6811118G20000

Unit Price

3
CAP SET, FUEL TANK FILLER

44200-16850-000  

44200-16852-000
 4420016850000

Unit Price

4
BOLT, L:20<br />BOLT
BOLT, L:20
BOLT

09106-05017-000   0910605017000

0910605017000

Unit Price

5
SCREW<br />SCREW, FRONT
SCREW
SCREW, FRONT

09139-06029-000   0913906029000

0913906029000

Unit Price

6
WASHER(6.5X22X1.6)<br />WASHER
WASHER(6.5X22X1.6)
WASHER

09160-06054-000   0916006054000

0916006054000

Unit Price

7
CUSHION, FUEL TANK FR

44511-16G00-000  

44511-16G01-000
 4451116G00000

Unit Price

8
SPACER, FUEL TANK FR
SPACER

44512-16G00-000   4451216G00000

4451216G00000

Unit Price

9
CUSHION, FUEL TANK SIDE
CUSHION, SIDE

44541-16G00-000   4454116G00000

4454116G00000

Unit Price

10
BRACKET, REAR

44550-16G10-000   4455016G10000

4455016G10000
Not available
11
BOLT

01550-08203-000  

01550-08207-000
 0155008203000

Unit Price

12
DISCONTINUE
BRACKET, CENTER

44530-16G10-000   4453016G10000

4453016G10000
Not available
13
CUSHION, TANK RR BRACKET
CUSHION, BRACKET

44543-16G00-000  

4454316G00000
Not available
14
SPACER, FUEL TANK
SPACER, JOINT

44561-35F00-000   4456135F00000

4456135F00000

Unit Price

15
BOLT 6X100
BOLT, JOINT

09103-06060-000   0910306060000

0910306060000

Unit Price

16
BRACKET, FUEL TANK RR UP
BRACKET, REAR UPPER

44570-16G00-000   4457016G00000

4457016G00000

Unit Price

17
CUSHION, FUEL TANK RR
CUSHION

44542-16G00-000   4454216G00000

4454216G00000

Unit Price

18
NUT

08319-31063-000  

08319-3106A-000
 0831931063000

Unit Price

19
STAY, FUEL TANK

44574-16G00-000   4457416G00000

4457416G00000

Unit Price

20
HOSE, WATER DRAIN

44423-16G10-000  

44423-16G11-000
 4442316G10000

Unit Price

21
CLAMP(L:80)

09404-06433-000  

09404-06036-000
 0940406433000

Unit Price

22
HOSE, FUEL TANK BREATHER

44424-16G00-000  

44424-18G01-000
 4442416G00000

Unit Price

23
SHIELD, FUEL TANK HEAT

44191-16G00-000   4419116G00000

4419116G00000

Unit Price

24
CLAMP(L:80)

09404-06433-000  

09404-06036-000
 0940406433000

Unit Price

25
SHEET, HEAT SHIELD RUBBER
SHEET, HEAT RUBBER

44271-16G10-000   4427116G10000

4427116G10000

Unit Price

26
CUSHION, FUEL TANK

44545-16G00-000   4454516G00000

4454516G00000

Unit Price

27
DISCONTINUE
MOLDING, TANK

68241-16G00-000  

6824116G00000
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
