WIRING HARNESS (MODELE K2 / K3) FOR SUZUKI V-STROM 1000 2003

Item numbers
WIRING HARNESS (MODELE K2/K3) Suzuki MOTO 1000 V-STROM 2003  DL1000 K3 (E03,E28,E33)
1
1
2
2
2
2
3
4
5
6
7
8
8
9
10
10
11
12
13
13
14
15
16
17
18
19
20
21
22
23
24
1
HARNESS, WIRING NO.1

36610-06G10-0003661006G10000

3661006G10000
Not available

1
HARNESS, WIRING NO.1

36610-06G30-0003661006G30000

3661006G30000
Not available

2
.FUSE (10A)
.FUSE (10A)

09481-10501-0000948110501000

0948110501000

Unit Price


2
.FUSE (15A)

09481-15501-0000948115501000

0948115501000

Unit Price


3
GUIDE, WIRING HARNESS

36619-06G00-000

36619-06G01-000
3661906G00000

Unit Price


4
DISCONTINUE
HARNESS, WIRING NO.2

36620-06G10-0003662006G10000

3662006G10000
Not available

5
COVER,SPEEDOMETER COUPLER<br />.COVER, SPEEDOMETER
COVER, SPEEDOMETER COUPLER
.COVER, SPEEDOMETER

36618-33E00-0003661833E00000

3661833E00000

Unit Price


6
WIRE, INJECTOR LEAD

36859-06G00-0003685906G00000

3685906G00000

Unit Price


7
WIRE, HORN LEAD

36852-06G00-0003685206G00000

3685206G00000

Unit Price


8
CLAMP, L:80

09404-06431-000

09404-06038-000
0940406431000

Unit Price


8
CLAMP(L:65)
CLAMP(L:65)

09404-06432-000

09404-06039-000
0940406432000

Unit Price


9
CLAMP<br />CLAMP (L:145)
CLAMP
CLAMP (L:145)

09407-14407-0000940714407000

0940714407000

Unit Price


10
CLAMP, WATER HOSE

09407-14408-000

09407-17402-000
0940714408000

Unit Price


11
BAND,WIRING HARNESS<br />CLAMP (L:125)
BAND, WIRING HARNESS
CLAMP (L:125)

09407-14403-0000940714403000

0940714403000

Unit Price


12
BOLT

01550-06103-000

01550-0610A-000
0155006103000

Unit Price


13
LOCK SET

37000-06860-000

37000-06863-000
3700006860000

Unit Price


13
LOCK SET

37000-06870-0003700006870000

3700006870000
Not available

14
LOCK ASSY, STEERING

37100-06G00-000

37100-06G01-000
3710006G00000

Unit Price


15
BOLT<br />SCREW (8X20)
BOLT
SCREW (8X20)

09139-08016-0000913908016000

0913908016000

Unit Price


16
SWITCH ASSY, STOP LAMP
SWITCH ASSY, STOP LAMP

37740-31D00-0003774031D00000

3774031D00000

Unit Price


17
SPRING, STOP LAMP SWITCH
SPRING, STOP LAMP

43259-06G00-0004325906G00000

4325906G00000

Unit Price


18
SWITCH ASSY, SIDE STAND

37840-06G00-000

37840-06G02-000
3784006G00000

Unit Price


19
BOLT

01550-06163-000

01550-0616A-000
0155006163000

Unit Price


20
HORN ASSY

38500-41F00-0003850041F00000

3850041F00000

Unit Price


21
BOLT

01550-08123-000

01550-0812A-000
0155008123000

Unit Price


22
NUT

08316-10083-000

08316-1008A-000
0831610083000

Unit Price


23
RELAY ASSY<br />RELAY ASSY, FUEL PUMP
RELAY ASSY
RELAY ASSY, FUEL PUMP

38740-24X50-0003874024X50000

3874024X50000

Unit Price


24
KEY, BLANK
KEY, BLANK

37146-33E00-0003714633E00000

3714633E00000

Unit Price


Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the WIRING HARNESS (MODELE K2/K3) of your Suzuki of V-STROM. Let us know if you have any questions.
