CAMSHAFT - VALVES

TIMING FOR SUZUKI V-STROM 1000 2007

THROTTLE BODY

Item numbers
TIMING Suzuki MOTO 1000 V-STROM 2007 DL1000K7(E2)
1
1
2
2
3
4
5
5
6
7
8
9
10
11
12
13
14
15
16
16
17
17
18
18
19
20
21
22
23
24
25
26
27
28
28
28
28
28
28
28
28
28
28
28
28
1
CHAIN, CAMSHAFT DRIVE

12760-23F00-000   1276023F00000

1276023F00000

Unit Price

2
GUIDE, CAM CHAIN

12771-06G00-000   1277106G00000

1277106G00000

Unit Price

3
TENSIONER, CAM CHAIN FR

12810-06G00-000   1281006G00000

1281006G00000

Unit Price

4
TENSIONER, CAM CHAIN RR
TENSIONER, CAM CHAIN, REAR

12815-06G00-000   1281506G00000

1281506G00000

Unit Price

5
BOLT
BOLT

07120-0612B-000   071200612B000

071200612B000

Unit Price

6
ADJUSTER ASSY, TENSIONER FR
ADJUSTER ASSY, TENSIONER, FRONT

12832-05A10-000   1283205A10000

1283205A10000

Unit Price

7
.GASKET(12X21X2)

09168-12018-000  

0916812018000
Not available
8
ADJUSTER ASSY,TENSIONER
ADJUSTER ASSY, TENSIONER

12830-30A01-000   1283030A01000

1283030A01000

Unit Price

9
.O RING
.O RING

12832-02A00-000   1283202A00000

1283202A00000

Unit Price

10
.SPRING
.SPRING

12833-30A01-000   1283330A01000

1283330A01000

Unit Price

11
.PLUG,ADJUSTER
.PLUG, ADJUSTER

12834-02A00-000   1283402A00000

1283402A00000

Unit Price

12
GASKET,TENSIONER ADJUSTER
GASKET, TENSIONER ADJUSTER

12837-19B10-000   1283719B10000

1283719B10000

Unit Price

13
GASKET,TENSIONER ADJUSTER
GASKET, TENSIONER ADJUSTER

12837-24A10-000   1283724A10000

1283724A10000

Unit Price

14
BOLT
BOLT

07130-0625B-000   071300625B000

071300625B000

Unit Price

15
BOLT
BOLT

07130-0620B-000   071300620B000

071300620B000

Unit Price

16
GEAR, CAM CHAIN IDLER NO.2
GEAR, CAM CHAIN IDLER NO.2(NT:31/41)

12750-06G00-000   1275006G00000

1275006G00000

Unit Price

17
SHAFT,IDLER,NO.2
SHAFT, IDLER, NO.2

12755-02F01-000   1275502F01000

1275502F01000

Unit Price

18
GASKET<br />GASKET,26.5X30.5X1(26.5X30.5X1)
GASKET
GASKET, 26.5X30.5X1(26.5X30.5X1)

09168-26001-000   0916826001000

0916826001000

Unit Price

19
KEY
KEY

09421-04004-000   0942104004000

0942104004000

Unit Price

20
SHAFT, IDLER

12716-06G00-000   1271606G00000

1271606G00000

Unit Price

21
SPR MOUNT DRUM NUT

09140-16001-000  

09140-16005-000
 0914016001000

Unit Price

22
SHIM(16X26X1.5)
SHIM(16X26X1.5)

09181-16212-000   0918116212000

0918116212000

Unit Price

23
BEARING

08112-63030-000   0811263030000

0811263030000

Unit Price

24
BEARING, ROLLER KOYO<br />BEARING(25X47X8)
BEARING, ROLLER KOYO
BEARING(25X47X8)

09262-25006-000   0926225006000

0926225006000

Unit Price

25
RETAINER<br />RETAINER,COUNTER BEARING RH
RETAINER
RETAINER, COUNTER BEARING RH

24741-20A00-000   2474120A00000

2474120A00000

Unit Price

26
SCREW<br />SCREW(6X12)
SCREW
SCREW(6X12)

09126-06011-000   0912606011000

0912606011000

Unit Price

27
SPROCKET, IDLER NO.1
SPROCKET, IDLER NO.1(NT:36)

12731-06G01-000   1273106G01000

1273106G01000

Unit Price

28
SHIM,15X24X0.9<br />SHIM,15X24X0.9(T:0.9)
SHIM, 15X24X0.9
SHIM, 15X24X0.9(T:0.9)

09181-15164-000   0918115164000

0918115164000

Unit Price

28
SHIM(15X24X1)<br />SHIM,15X24X1(T:1.0)
SHIM(15X24X1)
SHIM, 15X24X1(T:1.0)

09181-15166-000   0918115166000

0918115166000

Unit Price

28
SHIM(15X24X1.1)<br />SHIM,15X24X1.1(T:1.1)
SHIM(15X24X1.1)
SHIM, 15X24X1.1(T:1.1)

09181-15172-000   0918115172000

0918115172000

Unit Price

28
SHIM(15X24X1.2)<br />SHIM,15X24X1.2(T:1.2)
SHIM(15X24X1.2)
SHIM, 15X24X1.2(T:1.2)

09181-15176-000   0918115176000

0918115176000

Unit Price

28
SHIM(15X24X1.3)<br />SHIM,15X24X1.3(T:1.3)
SHIM(15X24X1.3)
SHIM, 15X24X1.3(T:1.3)

09181-15181-000   0918115181000

0918115181000

Unit Price

28
SHIM(15X24X1.4)<br />SHIM,15X24X1.4(T:1.4)
SHIM(15X24X1.4)
SHIM, 15X24X1.4(T:1.4)

09181-15182-000   0918115182000

0918115182000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the TIMING of your Suzuki V-STROM 1000 of V-STROM. Let us know if you have any questions.
