OIL COOLER

FUEL EVAP SYSTEM FOR SUZUKI BANDIT 1200 2006

CLUTCH

Item numbers
FUEL EVAP SYSTEM Suzuki MOTO 1200 BANDIT 2006 GSF1200AK6(E2)
1
2
3
4
5
5
5
5
6
6
6
6
7
7
7
7
8
9
10
11
12
13
14
15
16
16
17
18
1
DISCONTINUE
VLAVE ASSY, 2ND AIR

18450-24F20-000   1845024F20000

1845024F20000
Not available
2
BOLT

07130-06163-000  

07130-0616B-000
 0713006163000

Unit Price

3
DISCONTINUE
BRACKET, 2ND AIR

18610-38G00-000   1861038G00000

1861038G00000
Not available
4
BOLT (6X30)
BOLT (6X30)

09106-06089-000   0910606089000

0910606089000

Unit Price

5
HOSE, 2ND AIR VALVE NO.1
HOSE, 2ND AIR VALVE

18461-31F00-000   1846131F00000

1846131F00000

Unit Price

6
CLIP<br />CLIP, 2ND AIR HOSE PIPE
CLIP
CLIP, 2ND AIR HOSE PIPE

09401-13417-000   0940113417000

0940113417000

Unit Price

7
CLIP
CLIP

09401-13409-000   0940113409000

0940113409000

Unit Price

8
DISCONTINUE<br />PIPE, 2ND AIR NO.1
DISCONTINUE
PIPE, 2ND AIR NO.1

18410-31F00-000   1841031F00000

1841031F00000
Not available
9
DISCONTINUE
PIPE, 2ND AIR NO.2

18420-31F00-000   1842031F00000

1842031F00000
Not available
10
DISCONTINUE
PIPE, 2ND AIR NO.3

18430-31F00-000   1843031F00000

1843031F00000
Not available
11
DISCONTINUE<br />PIPE, 2ND AIR NO.4
DISCONTINUE
PIPE, 2ND AIR NO.4

18440-31F00-000   1844031F00000

1844031F00000
Not available
12
GASKET,2ND AIR PIPE<br />GASKET
GASKET, 2ND AIR PIPE
GASKET

18441-17C11-000   1844117C11000

1844117C11000

Unit Price

13
NUT 6MM

08316-10063-000  

08319-31067-000
 0831610063000

Unit Price

14
BOLT, STUD

01421-06163-000  

01421-0616A-000
 0142106163000

Unit Price

15
DISCONTINUE
HOSE, 2ND AIR CLEANER

18711-49G00-000  

1871149G00000
Not available
16
CLIP,BREATHER TUBE<br />CLIP
CLIP, BREATHER TUBE
CLIP

09401-15101-000   0940115101000

0940115101000

Unit Price

17
HOSE, VACUUM (4X7.5X8)

09359-40701-600   0935940701600

0935940701600
Not available
18
CLAMP,WIRING HARNESS<br />CLAMP
CLAMP, WIRING HARNESS
CLAMP

09407-18402-000   0940718402000

0940718402000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FUEL EVAP SYSTEM of your Suzuki BANDIT 1200 of BANDIT. Let us know if you have any questions.

Genuine parts for Suzuki 1200 BANDIT 2006

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 1200 BANDIT 2006

Select your Suzuki 2006 model

1200 BANDIT 2006 GSF1200AK6(E2)
1200 BANDIT 2006 GSF1200AK6(E2)

BANDIT 1200

Suzuki BANDIT

Displacement: 1200 cc
Year: 2006
Model code GSF1200AK6(E2)
