Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

LEVERS - HANDGRIPS (DR-Z125LL2 E33)

FRONT FORK (DR-Z125L2 E28) FOR SUZUKI DR-Z 125 2012

FRONT FORK (DR-Z125L2 E33)

Item numbers
FRONT FORK (DR-Z125L2 E28) Suzuki MOTO 125 DR-Z 2012 DR-Z125LL2(E28)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1
DAMPER ASSY, FR FORK, R
DAMPER ASSY, FRONT FORK RH

51103-08G40-000   5110308G40000

5110308G40000

Unit Price

2
DAMPER ASSY, FR FORK, L
DAMPER ASSY, FRONT FORK LH

51104-08G40-000   5110408G40000

5110408G40000

Unit Price

3
TUBE, OUTER, R
TUBE, OUTER RH

51130-08G00-000   5113008G00000

5113008G00000

Unit Price

4
TUBE, OUTER, L
TUBE, OUTER LH

51140-08G00-000   5114008G00000

5114008G00000

Unit Price

5
BUSH, GUIDE

51152-43EC0-000   5115243EC0000

5115243EC0000

Unit Price

6
SPACER, SEAL

51168-43EC0-000   5116843EC0000

5116843EC0000

Unit Price

7
SEAL, OIL
SEAL, OIL

51153-48420-000   5115348420000

5115348420000

Unit Price

8
SEAL, OIL STOPPER RING
RING, STOPPER

51156-48730-000   5115648730000

5115648730000

Unit Price

9
TUBE, INNER

51110-08G00-000   5111008G00000

5111008G00000

Unit Price

10
51121-08G10
BUSH, SLIDE

51121-08G00-000   5112108G00000

5112108G00000
Not available
11
PIECE, OIL LOCK

51195-48000-000   5119548000000

5119548000000

Unit Price

12
GASKET
GASKET

51148-36011-000   5114836011000

5114836011000

Unit Price

13
BOLT(8X27)<br />BOLT, CENTER
BOLT(8X27)
BOLT, CENTER

51147-48130-000   5114748130000

5114748130000

Unit Price

14
SPRING, FR
SPRING, FRONT

51171-08G00-000   5117108G00000

5117108G00000

Unit Price

15
BOLT
BOLT, FORK

51351-48000-000   5135148000000

5135148000000

Unit Price

16
O RING

51181-25030-000   5118125030000

5118125030000

Unit Price

17
CYLINDER

51146-08G00-000   5114608G00000

5114608G00000

Unit Price

18
SPRING, REBOUND

51177-08G00-000   5117708G00000

5117708G00000

Unit Price

19
RING

51196-48000-000   5119648000000

5119648000000

Unit Price

20
BOOT

51571-08G40-000   5157108G40000

5157108G40000

Unit Price

21
BAND

51575-08G00-000   5157508G00000

5157508G00000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for Suzuki 125 DR-Z 2012
