SPEEDOMETER

HEADLIGHT FOR SUZUKI DR 125 2002

INDICATORS

Item numbers
HEADLIGHT Suzuki MOTO 125 DR 2002 DR125SEK2(E2)
1
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
17
18
19
20
21
1
HEADLAMP ASSY

35100-42A50-999   3510042A50999

3510042A50999
Not available
1
HEADLAMP ASSY

35100-42A60-999   3510042A60999

3510042A60999
Not available
2
LAMP UNIT

35121-14A51-000   3512114A51000

3512114A51000
Not available
2
LAMP UNIT

35121-42A60-000   3512142A60000

3512142A60000
Not available
3
HOUSING
RING, MOUNTING

35141-14A00-000   3514114A00000

3514114A00000

Unit Price

4
SCREW

02112-05207-000  

02112-75207-000
 0211205207000

Unit Price

5
WASHER(5.5X18X1)<br />WASHER (5.5X18X1.0)
WASHER(5.5X18X1)
WASHER (5.5X18X1.0)

09160-05045-000   0916005045000

0916005045000

Unit Price

6
DISCONTINUE
SPACER

35133-14A00-000   3513314A00000

3513314A00000
Not available
7
CUSHION

35139-45230-000   3513945230000

3513945230000

Unit Price

8
NUT
NUT

35135-45900-000   3513545900000

3513545900000

Unit Price

9
SCREW
SCREW

35151-45900-000   3515145900000

3515145900000

Unit Price

10
* 35154-31C00
SPRING

35154-49200-000   3515449200000

3515449200000

Unit Price

11
CAP,SCREW<br />COVER, SPRING
CAP, SCREW
COVER, SPRING

35158-43400-000   3515843400000

3515843400000

Unit Price

12
NUT
NUT

35135-45600-000   3513545600000

3513545600000

Unit Price

13
DISCONTINUE
HOLDER, VALVE

35136-01A00-000   3513601A00000

3513601A00000
Not available
14
COVER, SOCKET

35173-01440-000   3517301440000

3517301440000

Unit Price

15
SOCKET

36118-12E20-000   3611812E20000

3611812E20000
Not available
15
SOCKET

36118-42A60-000   3611842A60000

3611842A60000
Not available
16
JOINT,RUBBER<br />RUBBER, JOINT
JOINT, RUBBER
RUBBER, JOINT

36116-22630-000   3611622630000

3611622630000

Unit Price

17
BULB(12V, 5W)
BULB (12V, 60/55W)

09471-12060-000  

0947112060000
Not available
18
BULB (12V, 4W)

09471-12063-000  

0947112063000
Not available
19
BOLT<br />BOLT (6X20)
BOLT
BOLT (6X20)

09116-06167-000   0911606167000

0911606167000

Unit Price

20
SPACER,6.5X10X7
SPACER, 6.5X10X7

09180-06263-000  

09180-06283-000
 0918006263000

Unit Price

21
CUSHION

09320-09018-000   0932009018000

0932009018000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the HEADLIGHT of your Suzuki DR 125 of DR. Let us know if you have any questions.

Genuine parts for Suzuki 125 DR 2002
