LEVERS - HANDGRIPS

FRONT FORK FOR SUZUKI GN 125 1997

STEERING COLUMN (MODEL V / W / X) REFER TO FIG.39A(H-4) FOR MODEL Y/K1

Item numbers

FRONT FORK Suzuki MOTO 125 GN 1997 GN125EV(E2)

1

DISCONTINUE
TUBE, OUTER RH

51130-05300-000 5113005300000

Not available

2

DISCONTINUE
TUBE, OUTER LH

51140-05300-000 5114005300000

Not available

3

SEAL, OIL
OIL SEAL

51153-05300-000 5115305300000

$19,97

Unit Price

4

RING, SNAP
RING, STOPPER

51156-41603-000 5115641603000

$11,97

Unit Price

5

GASKET

51148-41310-000 5114841310000

$3,97

Unit Price

6

BOLT, FORK CYLINDER(10X25)
BOLT

51147-16510-000 5114716510000

$6,97

Unit Price

7

SEAL, DUST
DUST SEAL

51173-41603-000 5117341603000

$16,97

Unit Price

8

PIECE, OIL LOCK

51195-36220-000 5119536220000

$17,97

Unit Price

9

DISCONTINUE
CYLINDER

51146-05300-000 5114605300000

Not available

10

DISCONTINUE
TUBE, INNER

51110-05300-000 5111005300000

Not available

11

DISCONTINUE
SPRING

51171-05300-000 5117105300000

Not available

12

GUIDE, SPRING

51172-39680-000 5117239680000

Not available

13

DISCONTINUE
SPACER

51176-05300-000 5117605300000

Not available

14

DISCONTINUE
O RING

51181-29400-000

Not available

15

CAP

51351-41603-000 5135141603000

$29,97

Unit Price

99x

DAMPER ASSY, FRONT FORK RH

51103-05301-000 5110305301000

Not available

99x

DISCONTINUE
DAMPER ASSY, FRONT FORK LH

51104-05301-000 5110405301000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
