FRONT FORK (MODEL H) REFER TO FIG.31A (F-4) FOR MODEL J

FRONT FORK (MODEL J) FOR SUZUKI RM 125 1988

STEERING COLUMN (MODEL G / H) REFER TO FIG.32A (F-6) FOR MODEL J

OUTER TUBE, RH

51130-01B40-000 5113001B40000

Not available

OUTER TUBE, LH

51140-01B40-000 5114001B40000

Not available

METAL, SLIDE

51167-14200-000

51167-40C00-000

$18,97

Unit Price

WASHER

51158-14200-000 5115814200000

$7,97

Unit Price

DISCONTINUE

51153-01B40-000

Not available

DUST SEAL

51173-01B40-000 5117301B40000

Not available

RING, STOPPER

51156-14200-000 5115614200000

$7,97

Unit Price

GASKET

51148-01B40-000 5114801B40000

Not available

51170-26C10
VALVE

51170-01B40-000 5117001B40000

Not available

CAP, VALVE

51189-14500-000 5118914500000

Not available

BOLT

01107-08307-000

01500-08307-000

$4,97

Unit Price

8 MM LOCK WASHER

08321-21088-000

08321-01087-000

$3,97

Unit Price

PIECE, OIL LOCK

51195-01B40-000 5119501B40000

Not available

CYLINDER

51146-01B40-000 5114601B40000

Not available

RING

51196-00B20-000 5119600B20000

Not available

INNER TUBE

51110-01B40-000 5111001B40000

Not available

DISCONTINUE
PISTON

51121-14200-000 5112114200000

Not available

SPRING

51171-00B20-000 5117100B20000

Not available

GUIDE, SPRING

51172-14280-000 5117214280000

Not available

CAP

51351-01B40-000 5135101B40000

Not available

O RING

51117-14200-000

51117-14201-000

$4,97

Unit Price

NUT, PISTON ROD

51129-01B40-000 5112901B40000

Not available

ROD, PISTON

51128-01B40-000 5112801B40000

Not available

DISCONTINUE
CAP

51188-01B20-000 5118801B20000

Not available

51571-32E00-38K
BOOT (YELLOW)

51571-01B20-25Y

Not available

DISCONTINUE
BAND, BOOT UPPER

51575-01B20-000 5157501B20000

Not available

DISCONTINUE
SCREW

51577-01B20-000 5157701B20000

Not available

BAND, BOOT LWR
BAND, BOOT LOWER

51576-00B00-000 5157600B00000

$15,97

Unit Price

PROTECTOR, RH (YELLOW)

51201-14500-163 5120114500163

Not available

PROTECTOR, LH (YELLOW)

51202-14501-163 5120214501163

Not available

DAMPER ASSY, RH

51103-01B40-000 5110301B40000

Not available

DAMPER ASSY, LH

51104-01B50-000 5110401B50000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
