REAR CALIPERS (MODEL R)

REAR BRAKE MASTER CYLINDER (MODEL K) FOR SUZUKI TS-R 125 1992

REAR BRAKE MASTER CYLINDER (MODEL L / M / N / P / R)

Item numbers

CYLINDER ASSY, REAR MASTER

69600-03D00-000 6960003D00000

Not available

PISTON/CUP SET

69600-04820-000

69600-04821-000

$87,97

Unit Price

BOOT

69691-00A00-000 6969100A00000

$8,97

Unit Price

YOKE

69692-27A30-000 6969227A30000

$26,97

Unit Price

ROD, PUSH

69670-00B21-000 6967000B21000

$45,97

Unit Price

NUT

69693-05A00-000 6969305A00000

$3,97

Unit Price

CONNECTOR

69672-00B20-000 6967200B20000

$12,97

Unit Price

O RING CONECTOR
O RING

69686-34200-000 6968634200000

$6,97

Unit Price

CIRCLIP

69674-00B20-000 6967400B20000

$6,97

Unit Price

BOLT

09106-06064-000 0910606064000

$10,97

Unit Price

TANK ASSY, REAR BRAKE
TANK ASSY, RESERVOIR

69740-03D00-000 6974003D00000

$90,97

Unit Price

CAP

69669-03D00-000 6966903D00000

$30,97

Unit Price

PLATE

69668-00B20-000 6966800B20000

$10,97

Unit Price

DIAPHRAGM
DIAPHRGM

69667-00B20-000 6966700B20000

$29,97

Unit Price

BOLT

01517-06128-000

01550-06207-000

$3,97

Unit Price

DISCONTINUE

69731-03D00-000

Not available

CLAMP.RESERVOIR HOSE
CLAMP

69735-00B20-000 6973500B20000

$6,97

Unit Price

HOSE, REAR BRAKE

69480-03D00-000 6948003D00000

Not available

UNION

09360-10017-000

09360-10061-000

$10,97

Unit Price

WASHER
WASHER (10X15X1.5)

09161-10009-000 0916110009000

$3,97

Unit Price

ADAPTOR, BRAKE HOSE
ADAPTER, HOSE

59290-14501-000 5929014501000

$36,97

Unit Price

GUIDE, RR BRAKE HOSE
CLAMP, REAR BRAKE HOSE

61196-03D00-000 6119603D00000

$10,97

Unit Price

SCREW

02112-35168-000

02112-3516A-000

$3,97

Unit Price

09200-06037-000

09200-06068-000

$7,97

Unit Price

WASHER

08322-21067-000

08322-0106A-000

$3,97

Unit Price

04111-20158-000

04111-2015A-000

$2,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the REAR BRAKE MASTER CYLINDER (MODEL K) of your Suzuki of TS-R. Let us know if you have any questions.
