Parts catalogue

Parts diagram

OIL PUMP

FUEL PUMP FOR SUZUKI BURGMAN 125 2002

WATER PUMP

FUEL PUMP Suzuki SCOOTER 125 BURGMAN 2002 UH125K2(P2)
1
PUMP ASSY, FUEL

15100-49F00-000   1510049F00000

1510049F00000
Not available
2
DISCONTINUE

D1507-06208-000  

D150706208000
Not available
3
WASHER

D8322-01065-000  

08322-0106A-000
 D832201065000

Unit Price

4
HOSE, FUEL

15801-07E00-000   1580107E00000

1580107E00000
Not available
5
CLIP

D9510-0115P-000   D95100115P000

D95100115P000
Not available
6
SPRING (L:470)

09440-C13-027J000   09440C13027J000

09440C13027J000
Not available
7
HOSE (5X10X660)

09355-C50-105J660   09355C50105J660

09355C50105J660
Not available
8
CLAMP

09404-C06-433JEE3   09404C06433JEE3

09404C06433JEE3
Not available
9
CLAMP

09407-07E00-000  

09407-11402-000
 0940707E00000

Unit Price

10
SPRING, VACUUM HOSE (L:470)

09440-C13-027J000   09440C13027J000

09440C13027J000
Not available
11
SPRING, VACUUM HOSE (L:200)

09440-C13-017J000   09440C13017J000

09440C13017J000
Not available
12
HOSE, VACUUM NO.2

09355-C50-105J040   09355C50105J040

09355C50105J040
Not available
13
JOINT, VACUUM HOSE 3WAY

09367-C06-008J000   09367C06008J000

09367C06008J000
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FUEL PUMP of your Suzuki BURGMAN 125 of BURGMAN. Let us know if you have any questions.

Genuine parts for Suzuki 125 BURGMAN 2002

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 125 BURGMAN 2002

Select your Suzuki 2002 model

125 BURGMAN 2002 UH125K2(P2)

BURGMAN 125

Suzuki BURGMAN

Displacement: 125 cc
Year: 2002
Model code UH125K2(P2)
