HANDLEBAR FOR SUZUKI BURGMAN 125 2003

LEVERS - HANDGRIPS

HANDLEBAR Suzuki SCOOTER 125 BURGMAN 2003 UH125K3(P2)
1
HANDLEBAR

56110-49F00-EE3   5611049F00EE3

5611049F00EE3
Not available
2
SCREW
SCREW, HANDLEBAR

09120-08016-000  

0912008016000
Not available
3
BOLT, CLAMP

09689-10116-000   0968910116000

0968910116000
Not available
4
NUT, CLAMP

D8311-79108-000   D831179108000

D831179108000
Not available
5
COVER, HANDLE UPPER (GRAY)

56311-49F00-Y0J   5631149F00Y0J

5631149F00Y0J
Not available
6
COVER, HANDLE LOWER RH (GRAY)

56321-49F00-Y0J   5632149F00Y0J

5632149F00Y0J
Not available
7
COVER, HANDLE LOWER LH (GRAY)

56331-49F00-Y0J   5633149F00Y0J

5633149F00Y0J
Not available
7A
EMBLEM "BURGMAN EXECUTIVE"

68281-C07-E00J000   68281C07E00J000

68281C07E00J000
Not available
8
SCREW

03541-04165-000  

03541-0416A-000
 0354104165000

Unit Price

9
NUT

D91EE-04166-000   D91EE04166000

D91EE04166000
Not available
10
SCREW

D2116-05125-000  

02112-0512A-000
 D211605125000

Unit Price

11
SCREW

D2126-06355-000   D212606355000

D212606355000
Not available
11
SCREW

D2126-06357-000   D212606357000

D212606357000
Not available
12
CAP, BALANCER

56274-C14-F00J000   56274C14F00J000

56274C14F00J000
Not available
12
CAP

56274-C33-400JEE3   56274C33400JEE3

56274C33400JEE3
Not available
13
SPACER

09180-C12-141J000   09180C12141J000

09180C12141J000
Not available
14
SPACER, BALANCER

56275-C34-401J000   56275C34401J000

56275C34401J000
Not available
15
MIRROR ASSY, RR VIEW RH

56500-49F00-000   5650049F00000

5650049F00000
Not available
16
MIRROR ASSY, RR VIEW RH&LH

56500-C07-E20J000   56500C07E20J000

56500C07E20J000
Not available
16
MIRROR ASSY, RR VIEW LH

56600-49F00-000   5660049F00000

5660049F00000
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the HANDLEBAR of your Suzuki BURGMAN 125 of BURGMAN. Let us know if you have any questions.

Genuine parts for Suzuki 125 BURGMAN 2003

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 125 BURGMAN 2003

Select your Suzuki 2003 model

125 BURGMAN 2003 UH125K3(P2)

BURGMAN 125

Suzuki BURGMAN

Displacement: 125 cc
Year: 2003
Model code UH125K3(P2)
