FRAME

FOOTREST FOR SUZUKI HAYABUSA 1300 2004

FUEL TANK (MODEL K4) COLOR : NY2=YD8(SILVER),YBA(BLUE)

Item numbers

DISCONTINUE
BRACKET, FRONT FOOTREST RH

43510-24F00-000 4351024F00000

Not available

DISCONTINUE
BRACKET, FRONT FOOTREST LH

43521-24F00-000 4352124F00000

Not available

BOLT(8X30)
BOLT, BRACKET

09106-08147-000 0910608147000

$9,97

Unit Price

WASHER(13.7X24X2)
WASHER, OUTER

09161-13004-000 0916113004000

$5,97

Unit Price

BUSH(8.4X20X16)
BUSH

09319-08045-000 0931908045000

$33,97

Unit Price

WASHER(17.2X24X2.2)
WASHER, INNER

09161-17002-000 0916117002000

$6,97

Unit Price

BAR, FR FOOTREST, R
BAR, FRONT FOOTREST RH

43531-24F00-000 4353124F00000

$81,97

Unit Price

BAR, FR FOOTREST, L
BAR, FRONT FOOTREST LH

43541-24F00-000 4354124F00000

$81,97

Unit Price

RUBBER, FOOTREST BAR
RUBBER

43550-24F00-000 4355024F00000

$39,97

Unit Price

09208-08016-000 0920808016000

$6,97

Unit Price

E RING

08332-11063-000

08332-1106B-000

$2,97

Unit Price

SPRING

09448-18022-000 0944818022000

$6,97

Unit Price

BALANCER, FR FOOTREST LWR
BALANCER

43536-31E20-000 4353631E20000

$65,97

Unit Price

SCREW

02142-05353-000

02142-0535B-000

$3,97

Unit Price

SCREW

02142-05253-000

02142-0525B-000

$3,97

Unit Price

BOLT, BANK SENSOR
BOLT, BANK SENS0R RH

43576-48B02-000 4357648B02000

$10,97

Unit Price

BOLT, BANK SENSOR
BOLT, BANK SENSOR LH

43576-48B20-000 4357648B20000

$15,97

Unit Price

DISCONTINUE
FOOTREST ASSY, PILLION RH

43600-24F00-000 4360024F00000

Not available

DISCONTINUE
FOOTREST ASSY, PILLION LH

43700-24F00-000 4370024F00000

Not available

DISCONTINUE
BAR, PILLION RH

43610-33E11-000 4361033E11000

Not available

BAR, PILLION FOOTREST, L
BAR, PILLION LH

43620-33E11-000 4362033E11000

$110,97

Unit Price

09208-06007-000 0920806007000

$5,97

Unit Price

SPRING

09440-05005-000 0944005005000

$2,97

Unit Price

STEEL BALL 7/32
BALL

06111-07004-000 0611107004000

$1,97

Unit Price

PLATE, PILLION FOOT, R
PLATE, RH

43816-33E21-000 4381633E21000

$37,97

Unit Price

PLATE, PILLION FOOT, L
PLATE, LH

43826-33E22-000 4382633E22000

$37,97

Unit Price

RING

08332-11043-000

08332-1104B-000

$2,97

Unit Price

BOLT
BOLT, BRACKET

09106-08121-000 0910608121000

$4,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FOOTREST of your Suzuki HAYABUSA 1300 of HAYABUSA. Let us know if you have any questions.
