SWINGARM

SHOCK ABSORBER LINKAGE FOR SUZUKI HAYABUSA 1300 2009

REAR WHEEL (MODEL K8 / K9) COLOR : CZY=YAY(BLACK),YHF(GRAY)

Item numbers
SHOCK ABSORBER LINKAGE Suzuki MOTO 1300 HAYABUSA 2009 GSX1300RK9(E2)
1
2
3
3
4
5
6
6
7
8
9
10
11
12
13
13
14
15
16
17
17
18
19
20
20
1
LEVER SET, RR CUSHION

62600-24831-000  

62600-24833-000
 6260024831000

Unit Price

2
ROLLER BEARING
ROLLER BEARING

09263-20073-000  

09263-20121-000
 0926320073000

Unit Price

3
BEARING
BEARING

09263-17037-000  

09263-17053-000
 0926317037000

Unit Price

4
BEARING
BEARING

09263-17034-000  

09263-17057-000
 0926317034000

Unit Price

5
SPACER,RR CUSHION LEVER FR<br />SPACER, FRONT (12X20X32)
SPACER, RR CUSHION LEVER FR
SPACER, FRONT (12X20X32)

62684-12C00-000   6268412C00000

6268412C00000

Unit Price

6
THRUST WASHER<br />WASHER
THRUST WASHER
WASHER

08211-12301-000   0821112301000

0821112301000

Unit Price

7
BOLT,RR CUSHION LEVER FR<br />BOLT, FRONT (12X78)
BOLT, RR CUSHION LEVER FR
BOLT, FRONT (12X78)

62658-19F00-000   6265819F00000

6265819F00000

Unit Price

8
NUT, REARCUSHION
NUT

09159-12056-000   0915912056000

0915912056000

Unit Price

9
SPACER,RR CUSHION LEVER CTR<br />SPACER, CENTER
SPACER, RR CUSHION LEVER CTR
SPACER, CENTER

62626-33D00-000   6262633D00000

6262633D00000

Unit Price

10
BOLT, RR CUSHION LEVER CTR
BOLT, CENTER

62621-33D10-000   6262133D10000

6262133D10000

Unit Price

11
NUT, REARCUSHION
NUT

09159-12056-000   0915912056000

0915912056000

Unit Price

12
SPACER,RR CUSHION LEVER<br />SPACER, REAR (10X17X30)
SPACER, RR CUSHION LEVER
SPACER, REAR (10X17X30)

62684-40A10-000   6268440A10000

6268440A10000

Unit Price

13
ROD, RR CUSHION
ROD, REAR CUSHION

62641-24F00-000   6264124F00000

6264124F00000

Unit Price

14
SPACER,RR CUSHION LEVER CTR<br />SPACER, ROD
SPACER, RR CUSHION LEVER CTR
SPACER, ROD

62626-33D00-000   6262633D00000

6262633D00000

Unit Price

15
BOLT, RR CUSHION LEVER CTR
BOLT, ROD

62621-33D10-000   6262133D10000

6262133D10000

Unit Price

16
NUT, REARCUSHION
NUT

09159-12056-000   0915912056000

0915912056000

Unit Price

17
DISCONTINUE
ABSORBER ASSY, REAR SHOCK

62100-24F50-000  

6210024F50000
Not available
17
ABSORBER ASSY, REAR SHOCK

62100-24F70-000   6210024F70000

6210024F70000
Not available
18
BOLT,10X70<br />BOLT, UPPER (10X70)
BOLT, 10X70
BOLT, UPPER (10X70)

09103-10033-000   0910310033000

0910310033000

Unit Price

19
BOLT 10 X 55
BOLT, LOWER (10X55)

09103-10143-000   0910310143000

0910310143000

Unit Price

20
NUT
NUT

09159-10115-000   0915910115000

0915910115000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SHOCK ABSORBER LINKAGE of your Suzuki HAYABUSA 1300 of HAYABUSA. Let us know if you have any questions.
