FUEL TANK (MODEL K3) REFER TO FIG.40B(G- 8) FOR MODEL K4

FUEL TANK (MODEL K4) FOR SUZUKI GSX 1400 2003

FUEL TANK (MODEL K5)

Item numbers

TANK ASSY, FUEL

44100-42FD0-CG9 4410042FD0CG9

Not available

TANK ASSY, FUEL

44100-42FD0-LR5 4410042FD0LR5

Not available

TANK ASSY, FUEL

44100-42FE0-CG9 4410042FE0CG9

Not available

TANK ASSY, FUEL

44100-42FE0-LR5 4410042FE0LR5

Not available

TAPE SET, FUEL TANK

68110-42F30-ML8 6811042F30ML8

Not available

TAPE SET, FUEL TANK

68110-42F30-MW6 6811042F30MW6

Not available

EMBLEM, FUEL TANK

68111-18G00-ABF

68111-18G01-0AT

$23,97

Unit Price

EMBLEM

68111-18G00-F9Y 6811118G00F9Y

Not available

TANK ASSY, FUEL (BLACK)

44100-42F10-YAY 4410042F10YAY

Not available

TANK ASSY, FUEL (BLACK)

44100-42F20-YAY 4410042F20YAY

Not available

EMBLEM, FUEL TANK

68111-18G00-ACV

68111-18G01-0AT

$23,97

Unit Price

44201-33822
CAP SET, FUEL TANK

44201-33820-000

Not available

BOLT, L:20
BOLT

09106-05017-000 0910605017000

$4,97

Unit Price

CUSHION, FRONT

44511-42F00-000 4451142F00000

Not available

CUSHION, SIDE

44541-42F00-000 4454142F00000

Not available

CLAMP

09407-25402-000 0940725402000

$8,97

Unit Price

CUSHION, FUEL TANK SI

44542-35F00-000

44542-35F01-000

$16,97

Unit Price

BRACKET, REAR

44550-42F00-000 4455042F00000

Not available

BOLT

01550-06123-000

01550-0612B-000

$3,97

Unit Price

CUSHION
CUSHION, LOWER

09320-10038-000 0932010038000

$4,97

Unit Price

CUSHION, FUEL TANK RR
CUSHION, UPPER

44512-42E00-000 4451242E00000

$8,97

Unit Price

SPACER, 6.5X9X18
SPACER

09180-06271-000 0918006271000

$3,97

Unit Price

BOLT

09116-06172-000 0911606172000

$4,97

Unit Price

HOSE, EATER DRAIN

44423-42F00-000 4442342F00000

Not available

HOSE, CONNECTING

44128-42F10-000 4412842F10000

Not available

CLAMP, WATER HOSE

09401-11407-000

09401-11415-000

$3,97

Unit Price

GAUGE, FUEL LEVEL

34810-42F00-000 3481042F00000

Not available

O RING
GASKET

34825-31F00-000 3482531F00000

$9,97

Unit Price

BOLT

07120-06123-000

07120-0612B-000

$5,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FUEL TANK (MODEL K4) of your Suzuki GSX 1400 of GSX. Let us know if you have any questions.
