FRONT FENDER (MODEL Y / K1) COLOR : K7E = 14L(WHITE), Y4L(YELLOW)

FRONT FENDER (MODEL K2) FOR SUZUKI INTRUDER 1500 2001

FRONT FENDER (MODEL K3 / K4) COLOR : LA1 = YD8(SILVER),YU8(GRAY)

Item numbers
FRONT FENDER (MODEL K2) Suzuki MOTO 1500 INTRUDER 2001 VL1500K1(E2)
1
2
3
3
4
5
6
7
8
8
9
10
10
10
11
11
11
12
13
1
DISCONTINUE
HOUSING, HEADLAMP

51810-10F00-000   5181010F00000

5181010F00000
Not available
2
BOLT,6X25<br />BOLT
BOLT, 6X25
BOLT

09116-06147-000   0911606147000

0911606147000

Unit Price

3
SPACER(6.8X12X11)
SPACER

09180-06076-000   0918006076000

0918006076000

Unit Price

4
BRACKET, HEADLAMP HOUSING
BRACKET

51850-10F01-000   5185010F01000

5185010F01000

Unit Price

5
01550-0616A
BOLT

01550-06163-000  

0155006163000
Not available
6
DISCONTINUE
PLATE, BRACKET RH

51871-10F00-000   5187110F00000

5187110F00000
Not available
7
DISCONTINUE
PLATE, BRACKET LH

51881-10F00-000   5188110F00000

5188110F00000
Not available
8
PROTECTOR(170X95X3.0)<br />CUSHION
PROTECTOR(170X95X3.0)
CUSHION

33651-37000-000   3365137000000

3365137000000

Unit Price

9
SCREW 6X12<br />SCREW
SCREW 6X12
SCREW

09139-06027-000   0913906027000

0913906027000

Unit Price

10
DISCONTINUE

53110-10F20-2AX  

5311010F202AX
Not available
10
DISCONTINUE

53110-10F20-JE2  

5311010F20JE2
Not available
10
DISCONTINUE

53110-10F20-JE3  

5311010F20JE3
Not available
11
DISCONTINUE
TAPE SET

68150-10F00-FH5   6815010F00FH5

6815010F00FH5
Not available
11
DISCONTINUE
TAPE SET

68150-10F00-JE4   6815010F00JE4

6815010F00JE4
Not available
11
DISCONTINUE
TAPE SET

68150-10F00-JE5   6815010F00JE5

6815010F00JE5
Not available
12
BOLT
BOLT

07130-08407-000   0713008407000

0713008407000

Unit Price

13
CAP
CAP

09250-06011-000   0925006011000

0925006011000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
