Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

REAR FAIRING (MODEL K8) COLOR : CRT = YHF(GRAY),YHG(GRAY)

REAR FAIRING (MODEL K9) FOR SUZUKI INTRUDER 1500 2008

FAIRING (MODEL K5 / K6 / K7) COLOR : NY3=YBA(BLUE), YAY(BLACK)

Item numbers
REAR FAIRING (MODEL K9) Suzuki MOTO 1500 INTRUDER 2008 VL1500K8(E2)
1
2
2
3
4
5
6
7
7
8
9
10
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
59
60
61
62
63
64
65
1
COVER, FRAME HEAD, R
COVER, FRAME HEAD RH

47510-10F01-000   4751010F01000

4751010F01000

Unit Price

2
COVER, FRAME HEAD, L
COVER, FRAME HEAD LH

47520-10F02-000   4752010F02000

4752010F02000

Unit Price

3
CUSHION(25X35X4)

47829-10F00-000  

44612-13600-000
 4782910F00000

Unit Price

4
MOLDING, FRAME HEAD COVER
MOLDING

47514-10F00-000   4751410F00000

4751410F00000

Unit Price

5
PROTECTOR, FRAME COVER
TAPE

47161-10D00-000   4716110D00000

4716110D00000

Unit Price

6
SCREW,6X20<br />SCREW
SCREW, 6X20
SCREW

09139-06028-000   0913906028000

0913906028000

Unit Price

7
DISCONTINUE
COVER ASSY, SIDE RH (BLACK)

47800-10F50-YAY   4780010F50YAY

4780010F50YAY
Not available
7
DISCONTINUE
COVER ASSY, SIDE RH (GRAY)

47800-10F50-YLF   4780010F50YLF

4780010F50YLF
Not available
8
EMBLEM, SIDE COVER, R
EMBLEM, RH

68111-10FA1-000   6811110FA1000

6811110FA1000

Unit Price

9
EMBLEM, RH

68111-10FB1-000   6811110FB1000

6811110FB1000
Not available
10
DISCONTINUE
COVER ASSY, SIDE LH (BLACK)

47900-10F50-YAY   4790010F50YAY

4790010F50YAY
Not available
10
DISCONTINUE
COVER ASSY, SIDE LH (GRAY)

47900-10F50-YLF   4790010F50YLF

4790010F50YLF
Not available
11
EMBLEM, SIDE COVER, R
EMBLEM, LH

68121-10FA1-000   6812110FA1000

6812110FA1000

Unit Price

12
EMBLEM, LH

68121-10FB1-000   6812110FB1000

6812110FB1000
Not available
13
SCREW
SCREW

09139-06030-000   0913906030000

0913906030000

Unit Price

14
SPACER, 6.5X9X7.2
SPACER

09180-06260-000   0918006260000

0918006260000

Unit Price

15
CUSHION (8.5X20X8)
CUSHION (8.5X20X8)

09320-08021-000  

09320-08510-000
 0932008021000

Unit Price

16
PROTECTOR, STARTING MOTOR LEAD
MOLDING

31812-29F00-000   3181229F00000

3181229F00000

Unit Price

17
CUSHION, SIDE UP METER & FRAME

47822-10F00-000  

47822-10F01-000
 4782210F00000

Unit Price

18
BOLT
BOLT, INNER

07120-0620A-000   071200620A000

071200620A000

Unit Price

19
WASHER, SIDE UPR COVER
WASHER

47827-10F00-000   4782710F00000

4782710F00000

Unit Price

20
CUSHION, SIDE UPR COVER

47826-10F00-000  

47826-10F01-000
 4782610F00000

Unit Price

21
DISCONTINUE
CUSHION, SIDE UPPER RH NO.1

47835-10FA0-000   4783510FA0000

4783510FA0000
Not available
22
DISCONTINUE
CUSHION, SIDE UPPER RH NO.2

47836-10FA0-000   4783610FA0000

4783610FA0000
Not available
23
MOLDING, SIDE UPR COVER UNDER
MOLDING, SIDE UPPER LOWER

47837-10FA0-000   4783710FA0000

4783710FA0000

Unit Price

24
CUSHION, BRACKET

47166-10FA0-000   4716610FA0000

4716610FA0000
Not available
25
BRACKET, SIDE COVER RH

47850-10FA0-000   4785010FA0000

4785010FA0000
Not available
26
CUSHION<br />CUSHION, RH
CUSHION
CUSHION, RH

09321-10034-000   0932110034000

0932110034000

Unit Price

27
CUSHION<br />CUSHION, LH
CUSHION
CUSHION, LH

09321-10012-000   0932110012000

0932110012000

Unit Price

28
BOLT
BOLT

01550-0616B-000   015500616B000

015500616B000

Unit Price

29
DISCONTINUE
TAPE, SHIELD

47164-10FA0-000   4716410FA0000

4716410FA0000
Not available
30
DISCONTINUE
CUSHION, SIDE FRONT

47165-10FA0-000   4716510FA0000

4716510FA0000
Not available
31
PROTECTOR, STARTING MOTOR LEAD
MOLDING, BREATHER HOSE

31812-29F00-000   3181229F00000

3181229F00000

Unit Price

32
PROTECTOR,CTR
PROTECTOR, CTR

17765-09F00-000  

17765-09F01-000
 1776509F00000

Unit Price

33
CLAMP,WIRING HARNESS<br />CLAMP
CLAMP, WIRING HARNESS
CLAMP

09407-18402-000   0940718402000

0940718402000

Unit Price

34
DISCONTINUE
BRACKET, SIDE UPPER RH

47839-10FA0-000   4783910FA0000

4783910FA0000
Not available
35
DISCONTINUE
BRACKET, SIDE UPPER LH

47849-10FA0-000   4784910FA0000

4784910FA0000
Not available
36
BOLT
BOLT

01550-0616B-000   015500616B000

015500616B000

Unit Price

37
CUSHION, BRACKET NO.1

47161-10FA0-000  

47161-10FA1-000
 4716110FA0000

Unit Price

38
DISCONTINUE
CUSHION, NO.2

47162-10FA0-000   4716210FA0000

4716210FA0000
Not available
39
DISCONTINUE
COVER, METER

47821-10FA0-000   4782110FA0000

4782110FA0000
Not available
40
MOLDING, METER COVER
MOLDING

47824-10FB0-000   4782410FB0000

4782410FB0000

Unit Price

41
SCREW<br />SCREW, FRONT
SCREW
SCREW, FRONT

09139-06030-000   0913906030000

0913906030000

Unit Price

42
CLUTCH REL WASHER

09160-06036-000  

09160-06019-000
 0916006036000

Unit Price

43
SPACER, 6.5X9X5.7
SPACER

09180-06256-000   0918006256000

0918006256000

Unit Price

44
CUSHION, MUF COV

09320-08051-000  

09320-08066-000
 0932008051000

Unit Price

45
CUSHION,LICENCE PLAT
CUSHION, LICENCE PLAT

09321-06013-000  

09321-06036-000
 0932106013000

Unit Price

46
BOLT<br />BOLT, CENTER
BOLT
BOLT, CENTER

07120-0625A-000   071200625A000

071200625A000

Unit Price

47
WASHER(6.5X18X1.6)<br />WASHER
WASHER(6.5X18X1.6)
WASHER

09160-06084-000   0916006084000

0916006084000

Unit Price

48
SPACER, 6.5X9X11
SPACER

09180-06265-000   0918006265000

0918006265000

Unit Price

49
CUSHION, METER COVER

47825-10F00-000  

47825-10F01-000
 4782510F00000

Unit Price

50
CUSHION, SIDE UP METER & FRAME

47822-10F00-000  

47822-10F01-000
 4782210F00000

Unit Price

51
BOLT
BOLT, REAR

07120-0616A-000   071200616A000

071200616A000

Unit Price

52
WASHER(6.5X18X1.6)<br />WASHER
WASHER(6.5X18X1.6)
WASHER

09160-06084-000   0916006084000

0916006084000

Unit Price

53
SPACER, 6.5X9X5.7
SPACER

09180-06256-000   0918006256000

0918006256000

Unit Price

54
CUSHION, MUF COV

09320-08051-000  

09320-08066-000
 0932008051000

Unit Price

55
CUSHION(25X35X4)

47829-10F00-000  

44612-13600-000
 4782910F00000

Unit Price

56
DISCONTINUE
HINGE, FUEL LID

47380-10F01-000   4738010F01000

4738010F01000
Not available
57
DISCONTINUE
LID, FUEL INLET

47811-10FA0-000   4781110FA0000

4781110FA0000
Not available
58
CUSHION, FUEL LID
CUSHION, LID

47812-10F00-000   4781210F00000

4781210F00000

Unit Price

59
SCREW
SCREW

02142-0612A-000  

02142-0612B-000
 021420612A000

Unit Price

60
LOCK SET, COVER

95700-07860-000  

95700-07861-000
 9570007860000

Unit Price

61
CUSHION, MUF COV

09320-08051-000  

09320-08066-000
 0932008051000

Unit Price

62
COVER, FUEL LID

47812-10FA0-000   4781210FA0000

4781210FA0000

Unit Price

63
SCREW

03541-0512A-000   035410512A000

035410512A000

Unit Price

64
DISCONTINUE
COVER, METER SWITCH

47822-10FA0-000   4782210FA0000

4782210FA0000
Not available
65
SCREW

03541-0512A-000   035410512A000

035410512A000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for Suzuki 1500 INTRUDER 2008

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 1500 INTRUDER 2008

Choose your Suzuki 1500 2008 INTRUDER model

1500 INTRUDER 2008 VL1500K8(E2)
1500 INTRUDER 2008 VL1500K8(E2)
1500 INTRUDER 2008 VL1500K8(E2)
1500 INTRUDER 2008 VL1500K8(E2)
1500 INTRUDER 2008 VL1500K8(E2)

Suzuki INTRUDER

Displacement: 1500 cc
Year: 2008
Model code VL1500K8(E2)
