FAIRING (VLR1800TK9) REFER TO FIG.44C(G- 5) FOR MODEL L0

FAIRING (MODEL L0) FOR SUZUKI INTRUDER 1800 2009

SIDE LOWER COVER

Item numbers

DISCONTINUE
COVER, FRAME RH (BLACK)

47110-22H00-YAY 4711022H00YAY

Not available

DISCONTINUE
COVER, FRAME RH (GRAY)

47110-22H00-YHG 4711022H00YHG

Not available

COVER, FRAME RH (BLACK)

47110-22H10-YAY 4711022H10YAY

Not available

COVER, FRAME RH (GRAY)

47110-22H10-YHG 4711022H10YHG

Not available

47110-22HA1-YAY
COVER, FRAME RH (BLACK)

47110-22HA0-YAY 4711022HA0YAY

Not available

COVER, FRAME RH (RED)

47110-22HA0-YMK 4711022HA0YMK

Not available

SHIELD, FRAME COVER, R
SHIELD, RH

47166-22H00-000 4716622H00000

$18,97

Unit Price

EMBLEM

68131-22H10-000 6813122H10000

Not available

68131-22H01
EMBLEM

68131-22H00-000 6813122H00000

Not available

68131-22HA1
EMBLEM

68131-22HA0-000 6813122HA0000

Not available

47210-22H01-YAY
COVER, FRAME LH (BLACK)

47210-22H00-YAY 4721022H00YAY

Not available

DISCONTINUE
COVER, FRAME LH (GRAY)

47210-22H00-YHG 4721022H00YHG

Not available

COVER, FRAME LH (BLACK)

47210-22H10-YAY 4721022H10YAY

Not available

COVER, FRAME LH (GRAY)

47210-22H10-YHG 4721022H10YHG

Not available

47210-22HA1-YAY
COVER, FRAME LH (BLACK)

47210-22HA0-YAY 4721022HA0YAY

Not available

COVER, FRAME LH (RED)

47210-22HA0-YMK 4721022HA0YMK

Not available

EMBLEM

68131-22H10-000 6813122H10000

Not available

68131-22H01
EMBLEM

68131-22H00-000 6813122H00000

Not available

68131-22HA1
EMBLEM

68131-22HA0-000 6813122HA0000

Not available

BODY, LUGGAGE BOX

92211-22H00-000 9221122H00000

$66,97

Unit Price

SCREW, 6X12
SCREW

09139-06152-000 0913906152000

$10,97

Unit Price

SCREW, 6X10
SCREW

09139-06172-000 0913906172000

$6,97

Unit Price

LID, LUGGAGE BOX
LID

92212-22H00-000 9221222H00000

$66,97

Unit Price

CUSHION(8X26X7)

09320-08018-000

09320-08513-000

$5,97

Unit Price

CUSHION

09320-08049-000 0932008049000

$6,97

Unit Price

LOCK SET, FRAME COVER

95700-07870-000 9570007870000

$191,97

Unit Price

BRACKET, FRAME COVER

47120-22H00-000 4712022H00000

$80,97

Unit Price

CUSHION(10X30X2)
CUSHION

44894-24A00-000 4489424A00000

$2,97

Unit Price

BOLT

01550-0610A-000

01550-0610B-000

$4,97

Unit Price

MOLDING, FRAME HEAD COVER
MOLDING

47514-10F00-000 4751410F00000

$15,97

Unit Price

O RING
BAND, TOOL

09280-61002-000

Not available

TOOL ASSY

09800-21055-000

09800-21102-000

$46,97

Unit Price

SPANNER, HEXAGON(6)
HEXAGON, SPANNER 6

09816-00050-000 0981600050000

$11,97

Unit Price

HEXAGON, SPANNER 5

09816-00059-000 0981600059000

$10,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
