TAIL LIGHT (E2, E26) REFER TO FIG.23A(E-7) FOR MODEL N/P/R E24

TAIL LIGHT (MODEL N / P / R E24) FOR SUZUKI TS-ER 185 1993

ELECTRICAL (MODEL Z / K,MODEL P E6,P9) REFER TO FIG 25A(E-10) FOR MODEL N,MODEL P/R E24

LAMP UNIT, TAIL

35720-48560-999 3572048560999

Not available

LENS

35712-02460-000 3571202460000

Not available

GASKET

35713-48510-000 3571348510000

$16,97

Unit Price

SCREW

03211-04306-000 0321104306000

$2,97

Unit Price

GASKET

35627-43010-000 3562743010000

$3,97

Unit Price

WASHER

08322-21055-000

08322-0105B-000

$3,97

Unit Price

WASHER, LOCK

08321-21055-000

08321-01053-000

$2,97

Unit Price

SCREW

02112-05125-000

02112-05127-000

$3,97

Unit Price

BULB (6V, 21/5W)

09471-06034-000 0947106034000

Not available

BRACKET ASSY

35730-30910-000 3573030910000

Not available

PLATE

35716-30950-000 3571630950000

Not available

CUSHION

35765-30950-000 3576530950000

Not available

SPACER

35766-30950-000 3576630950000

Not available

BOLT

01550-06307-000 0155006307000

$4,97

Unit Price

DISCONTINUE
BOLT

01570-06303-000

Not available

WASHER 6.5X10X1.2

09160-06027-000

09160-06077-000

$3,97

Unit Price

WASHER, LOCK
LOCK WASHER

08321-01067-000 0832101067000

$2,97

Unit Price

SPACER, 6.5X9X18

09180-06072-000

09180-06271-000

$3,97

Unit Price

CUSHION

09320-09003-000 0932009003000

$3,97

Unit Price

BOLT

01107-06408-000

01500-0640B-000

$4,97

Unit Price

BOLT

01570-06403-000 0157006403000

Not available

WASHER, LOCK
LOCK WASHER

08321-01067-000 0832101067000

$2,97

Unit Price

SPACER(6.5X10X11.5)

09180-06112-000

09180-06289-000

$4,97

Unit Price

09180-06289
SPACER (6.8X10X11.5)

09180-06006-000

Not available

CUSHION

09320-09010-000 0932009010000

$4,97

Unit Price

GROMMET

09308-07004-000 0930807004000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
