CARBURETOR FOR SUZUKI DR-Z 250 2006

AIR FILTER

Item numbers
CARBURETOR Suzuki MOTO 250 DR-Z 2006 DR-Z250K6(E24)
1
2
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
1
CARBURETOR ASSY

13200-13E30-000   1320013E30000

1320013E30000

Unit Price

2
COVER, TOP

13261-13E00-000   1326113E00000

1326113E00000

Unit Price

3
GASKET,CARBURETOR TOP<br />GASKET
GASKET, CARBURETOR TOP
GASKET

13266-27A00-000   1326627A00000

1326627A00000

Unit Price

4
JET, AIR
JET, AIR (1.2)

09493-24007-000   0949324007000

0949324007000

Unit Price

5
JET, AIR (1.6)

09493-32003-000   0949332003000

0949332003000
Not available
6
LEVER SET, THROTTLE
LEVER SET, THROTTLE

13541-13E00-000   1354113E00000

1354113E00000

Unit Price

7
WASHER
WASHER

13575-38200-000   1357538200000

1357538200000

Unit Price

8
PLATE
PLATE

13447-14A00-000   1344714A00000

1344714A00000

Unit Price

9
CLIP ASSY

13446-13E00-000   1344613E00000

1344613E00000

Unit Price

10
CONNECTOR

13398-27A02-000   1339827A02000

1339827A02000

Unit Price

11
SCREW
SCREW

02112-0312B-000   021120312B000

021120312B000

Unit Price

12
GASKET
GASKET

13445-14A00-000   1344514A00000

1344514A00000

Unit Price

13
WASHER<br />WASHER (4.5X8X0.5)
WASHER
WASHER (4.5X8X0.5)

09160-04024-000   0916004024000

0916004024000

Unit Price

14
E RING
E RING

13415-38300-000   1341538300000

1341538300000

Unit Price

15
VALVE, PISTON

13551-13E30-000   1355113E30000

1355113E30000

Unit Price

16
E RING
E RING

13394-40D20-000   1339440D20000

1339440D20000

Unit Price

17
NEEDLE, JET(6FN3-3)
NEEDLE, JET

13383-13E30-000   1338313E30000

1338313E30000

Unit Price

18
JET, NEEDLE (P-6M)

13341-13E30-000   1334113E30000

1334113E30000

Unit Price

19
SPRING

13494-14D00-000   1349414D00000

1349414D00000

Unit Price

20
PLUNGER ASSY

13411-42A20-000   1341142A20000

1341142A20000

Unit Price

21
O RING
O RING

13278-47090-000  

13278-47091-000
 1327847090000

Unit Price

22
SCREW, PILOT

13279-13E30-000   1327913E30000

1327913E30000

Unit Price

23
SPRING
SPRING

13268-47070-000   1326847070000

1326847070000

Unit Price

24
WASHER
WASHER

13291-29900-000   1329129900000

1329129900000

Unit Price

25
O RING,PILOT AIR SCREW
O RING, PILOT AIR SCREW

13295-29900-000  

13295-29901-000
 1329529900000

Unit Price

26
JET, PILOT (37.5)

09492-37002-000   0949237002000

0949237002000

Unit Price

27
RING,MAIN JET FIXING<br />RING
RING, MAIN JET FIXING
RING

13331-13A00-000   1333113A00000

1333113A00000

Unit Price

28
JET, MAIN
JET, MAIN (127.5)

09491-25011-000   0949125011000

0949125011000

Unit Price

29
VALVE ASSY, NEEDLE

13370-05530-000   1337005530000

1337005530000

Unit Price

30
O RING,NEEDLE VALVE SEAT<br />O RING
O RING, NEEDLE VALVE SEAT
O RING

13374-35C00-000   1337435C00000

1337435C00000

Unit Price

31
FILTER
FILTER

13376-19F00-000   1337619F00000

1337619F00000

Unit Price

32
SCREW
SCREW

13602-43410-000   1360243410000

1360243410000

Unit Price

33
FLOAT
FLOAT

13250-28A00-000   1325028A00000

1325028A00000

Unit Price

34
PIN, FLOAT
PIN, FLOAT

13254-92311-000   1325492311000

1325492311000

Unit Price

35
O RING,FLOAT CHAMBER<br />O RING
O RING, FLOAT CHAMBER
O RING

13251-27A00-000   1325127A00000

1325127A00000

Unit Price

36
SCREW
SCREW

02112-3410A-000   021123410A000

021123410A000

Unit Price

37
ADJUSTER

13267-13D01-000   1326713D01000

1326713D01000

Unit Price

38
RING

13331-13E00-000   1333113E00000

1333113E00000

Unit Price

39
SPRING

13268-13E00-000   1326813E00000

1326813E00000

Unit Price

40
SCREW

13602-48B10-000   1360248B10000

1360248B10000

Unit Price

41
PLUG,DRAIN<br />SCREW, DRAIN
PLUG, DRAIN
SCREW, DRAIN

13247-02340-000   1324702340000

1324702340000

Unit Price

42
BOOT
BOOT

13499-44500-000   1349944500000

1349944500000

Unit Price

43
ROD, PLUNGER
ROD

13487-14A00-000   1348714A00000

1348714A00000

Unit Price

44
PLUNGER
PLUNGER

13493-27A00-000   1349327A00000

1349327A00000

Unit Price

45
SPRING
SPRING

13271-09400-000   1327109400000

1327109400000

Unit Price

46
BOLT
BOLT

13613-14A00-000   1361314A00000

1361314A00000

Unit Price

47
LEVER
LEVER

13490-14A00-000   1349014A00000

1349014A00000

Unit Price

48
HOSE(5X9X600)
HOSE(5X9X600)

09352-50903-600  

09352-50006-600
 0935250903600

Unit Price

49
HOSE(5X9X600)
HOSE(5X9X600)

09352-50903-600  

09352-50006-600
 0935250903600

Unit Price

50
HOSE
HOSE

09352-30503-600  

09352-30504-600
 0935230503600

Unit Price

51
CLAMP<br />CLIP
CLAMP
CLIP

09408-00033-000   0940800033000

0940800033000

Unit Price

52
NET, INTAKE

13130-19B00-000   1313019B00000

1313019B00000

Unit Price

53
CLAMP(L:65)
CLAMP(L:65)

09404-06429-000  

09404-06039-000
 0940406429000

Unit Price
