ELECTRICAL

SPEEDOMETER (MODEL Z) FOR SUZUKI GSX 250 1983

SPEEDOMETER (MODEL D)

SPEEDOMETER (KILO)

34110-33200-000 3411033200000

Not available

SPEEDOMETER (MILE/KILO)

34110-33230-000 3411033230000

Not available

KNOB

34980-45020-000 3498045020000

$7,97

Unit Price

DISCONTINUE

34189-33220-000

Not available

COVER, SPEEDOMETER

34151-33220-000 3415133220000

Not available

TACHOMETER

34210-33220-000 3421033220000

Not available

DISCONTINUE

34189-33220-000

Not available

COVER, TACHOMETER

34251-33220-000 3425133220000

Not available

FUELMETER

34320-11500-000 3432011500000

Not available

WASHER

34384-33220-000 3438433220000

Not available

.LOCK WASHER

08321-21038-000 0832121038000

Not available

NUT

08310-11038-000

08310-00033-000

$3,97

Unit Price

LEAD WIRE, FUELMETER

34378-33220-000 3437833220000

Not available

SOCKET, PILOT LAMP

36325-11500-000 3632511500000

Not available

SOCKET, SPEEDOMETER

34173-44310-000 3417344310000

Not available

SOCKET, TACHOMETER

34273-33220-000 3427333220000

Not available

BULB(12V21W)
BULB (12V, 3.4W)

09471-12028-000

Not available

BULB(12V3.4W, T10, BF175-01450A)
BULB (12V, 1.7W)

09471-12077-000 0947112077000

$3,97

Unit Price

CASE, PILOT BOX

36381-11500-000 3638111500000

Not available

SEAL

34993-47000-000 3499347000000

Not available

BOX, PILOT

36382-11500-000 3638211500000

Not available

SCREW

36456-33220-000 3645633220000

Not available

PANEL

36386-11500-000 3638611500000

Not available

DISCONTINUE
CUSHION

34191-44310-000 3419144310000

Not available

CUSHION

36384-45300-000 3638445300000

Not available

COVER, PILOT BOX

36383-11500-000 3638311500000

Not available

.SCREW

02112-04168-000 0211204168000

Not available

BRACKET

34950-44400-000 3495044400000

Not available

DISCONTINUE

34189-44310-000

Not available

ORNAMENT, SPEEDOMETER

34193-33221-000 3419333221000

Not available

ORNAMENT, TACHOMETER

34293-33221-000 3429333221000

Not available

LOCK WASHER

08322-21058-000 0832221058000

Not available

NUT

08313-11057-000

08313-1005A-000

$3,97

Unit Price

CUSHION, METER BRACKET
CUSHION

34956-31001-000 3495631001000

$8,97

Unit Price

WASHER, 8.5X28X1.6

09160-08002-000

09160-08135-000

$3,97

Unit Price

NUT

08310-12088-000

08310-00087-000

$3,97

Unit Price

8 MM LOCK WASHER

08321-21088-000

08321-01087-000

$3,97

Unit Price

CABLE ASSY, SPEEDOMETER

34910-44400-000

34910-44401-000

$45,97

Unit Price

CLAMP, SPEEDOMETER CABLE
CLAMP

34938-45100-000 3493845100000

$28,97

Unit Price

BOLT, FENDER REAR

01107-06168-000 0110706168000

Not available

WASHER

08322-21068-000 0832221068000

Not available

CABLE, TACHOMETER

34940-33211-000 3494033211000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SPEEDOMETER (MODEL Z) of your Suzuki of GSX. Let us know if you have any questions.
