Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

CYLINDER

EXHAUST VALVE FOR SUZUKI RG 250 1996

CRANKCASE

Item numbers

ACTUATOR ASSY, EXHAUST VALVE

33970-22X50-000 3397022X50000

Not available

BOLT

01550-06303-000

01550-0630A-000

$3,97

Unit Price

NUT 6MM

08316-10063-000

08319-31067-000

$3,97

Unit Price

BOLT

01547-06163-000

01547-0616B-000

$4,97

Unit Price

BRACKET, CABLE

11286-12C01-000 1128612C01000

Not available

BRACKET, CABLE

11286-22D10-000 1128622D10000

Not available

PULLEY, CONTROLLER

11269-12C02-000 1126912C02000

Not available

PULLEY, CONTROLLER

11269-22D00-000 1126922D00000

Not available

PULLEY, CONTROLLER NO.2

16611-22D10-000 1661122D10000

Not available

SPRING

16613-22D00-000 1661322D00000

Not available

SPACER

09180-05043-000 0918005043000

Not available

BOLT

07120-05168-000 0712005168000

Not available

11A

BOLT (5X30)

09118-05004-000 0911805004000

Not available

VALVE SET, EXHAUST RH

11206-19D31-000 1120619D31000

Not available

VALVE SET, EXHAUST RH

11250-19810-000 1125019810000

Not available

VALVE SET, EXHAUST RH

11250-19830-000 1125019830000

Not available

VALVE SET, EXHAUST LH

11207-19D31-000 1120719D31000

Not available

VALVE SET, EXHAUST LH

11250-19820-000 1125019820000

Not available

VALVE SET, EXHAUST LH

11250-19840-000 1125019840000

Not available

SCREW

02142-05123-000

02142-0512A-000

$2,97

Unit Price

SPACER, EXHAUST VALVE

11263-08D11-000 1126308D11000

$26,97

Unit Price

SPACER, EXHAUST VALVE

11263-12C01-000 1126312C01000

Not available

PIN, EXHAUST VALVE

11253-01B31-000

11253-01B32-000

$35,97

Unit Price

SPRING

09440-03010-000 0944003010000

$5,97

Unit Price

RETAINER, EX VALVE SPRING

11274-22D01-000 1127422D01000

Not available

SHAFT, EX VALVE

11258-12C02-000 1125812C02000

Not available

DISCONTINUE

11264-00B23-000

Not available

SCREW

09134-06013-000 0913406013000

$6,97

Unit Price

BUSH

09300-08016-000 0930008016000

$5,97

Unit Price

SPACER, EX VALVE SHAFT

11283-12C00-000 1128312C00000

Not available

BUSH, EXHAUST VALVE NO.2
BUSH, EX VALVE NO.2

11265-12C00-000 1126512C00000

$14,97

Unit Price

OIL SEAL SPMETER GR
OIL SEAL (8X16X5)

09282-08001-000 0928208001000

$4,97

Unit Price

OIL SEAL (8X16X5)

09282-08004-000 0928208004000

Not available

RETAINER, OIL SEAL

11259-22D01-000 1125922D01000

Not available

SCREW

02122-06123-000

02122-0612B-000

$2,97

Unit Price

SCREW

02122-06127-000 0212206127000

$2,97

Unit Price

SCREW
SCREW (6X12)

09126-06011-000 0912606011000

$3,97

Unit Price

LEVER, EXHAUST VALVE

11267-12C02-000 1126712C02000

Not available

SCREW

09125-06058-000 0912506058000

Not available

WASHER

08211-06222-000 0821106222000

Not available

SPRING, EX VALVE LEVER

11285-22D00-000 1128522D00000

Not available

SPACER, EX VALVE PULLEY

11268-22D03-000 1126822D03000

Not available

PULLEY, EX VALVE

11266-22D01-000 1126622D01000

Not available

BOLT

09118-05005-000 0911805005000

$6,97

Unit Price

BOLT

01137-05128-000 0113705128000

Not available

WASHER

09160-05005-000 0916005005000

Not available

DISCONTINUE
CABLE, EX VALVE FRONT RH

11276-12C02-000 1127612C02000

Not available

CABLE, EXHAUST VALVE FR, L
CABLE, EX VALVE FRONT LH

11278-12C00-000 1127812C00000

$38,97

Unit Price

CABLE, EXHAUST VALVE RR, R
CABLE, EX VALVE REAR RH

11277-22D01-000 1127722D01000

$23,97

Unit Price

CABLE, EXHAUST VALVE RR, L
CABLE, EX VALVE REAR LH

11279-22D01-000 1127922D01000

$26,97

Unit Price

STOPPER, CABLE

11284-12C00-000 1128412C00000

$16,97

Unit Price

GUIDE, EX VALVE CABLE

11275-22D01-000 1127522D01000

Not available

CLAMP(L:65)

09404-06403-000

09404-06039-000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
