HEADLIGHT (E4)

INDICATORS (E4) FOR SUZUKI OZARK 250 2009

TAIL LIGHT (E17,E24)

Item numbers

LAMP ASSY, FRONT TURNSIGNAL

35601-42A50-000 3560142A50000

Not available

LENS, FR TURNSIGNAL LAMP
LENS

35612-01A70-000 3561201A70000

$13,97

Unit Price

GASKET

35613-28620-000 3561328620000

$14,97

Unit Price

BULB(12V60/55W, H4)
BULB (12V21W)

09471-12045-000 0947112045000

$5,97

Unit Price

SCREW

03211-04253-000

03211-0425B-000

$3,97

Unit Price

GASKET
PARKING

35627-43010-000 3562743010000

$3,97

Unit Price

NUT

08316-1012A-000 083161012A000

$3,97

Unit Price

LAMP ASSY, REAR R

35603-05G00-000 3560305G00000

Not available

LENS, R

35752-67H01-000 3575267H01000

Not available

LENS, TURNSIGNAL, R

35652-67H01-000 3565267H01000

Not available

BULB(12V1.4W G30)
BULB (12V21/5W)

09471-12083-000 0947112083000

$9,97

Unit Price

BULB(12V60W, HB3, #9005)
BULB (12V18W)

09471-12146-000

Not available

SCREW

02142-0510A-000 021420510A000

$2,97

Unit Price

LAMP ASSY, REAR, L

35604-05G00-000 3560405G00000

Not available

LENS, L

35772-67H01-000 3577267H01000

Not available

LENS, TURNSIGNAL, L

35672-67H01-000 3567267H01000

Not available

BULB(12V1.4W G30)
BULB (12V21/5W)

09471-12083-000 0947112083000

$9,97

Unit Price

BULB(12V60W, HB3, #9005)
BULB (12V18W)

09471-12146-000

Not available

SCREW

02142-0510A-000 021420510A000

$2,97

Unit Price

WASHER 6.5X10X1.2
WASHER (6.5X20X1.2)

09160-06077-000 0916006077000

$3,97

Unit Price

SPACER (6.5X9X8)

09180-06261-000 0918006261000

$3,97

Unit Price

RR COMB LAMP CUSHION
CUSHION

09320-09009-000 0932009009000

$7,97

Unit Price

BOLT

01547-06163-000

01547-0616B-000

$4,97

Unit Price

RELAYASSY, TURN

38610-06F00-000

38610-06F01-000

$93,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
