Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

RADIATOR

CLUTCH (MODEL F / G) FOR SUZUKI QUADRACER 250 1990

CLUTCH (MODEL H / J / K / L / M / N)

CLUTCH (MODEL F/G) Suzuki QUAD 250 QUADRACER 1990 LT250RL(E28)
1
GEAR, PRIMARY DRIVEN

21200-13A04-000   2120013A04000

2120013A04000
Not available
2
DISCONTINUE
SPACER

21251-14601-000   2125114601000

2125114601000
Not available
3
DISCONTINUE
BEARING

09263-25044-000   0926325044000

0926325044000
Not available
4
DISCONTINUE
HUB, SLEEVE

21411-13A01-000   2141113A01000

2141113A01000
Not available
5
DISCONTINUE
THRUST WASHER

09160-20054-000   0916020054000

0916020054000
Not available
6
WASHER
WASHER

09167-20006-000   0916720006000

0916720006000

Unit Price

7
DRIVE SPROCKET NUT

09140-20002-000  

09140-20001-000
 0914020002000

Unit Price

8
PLATE, CLUTCH DRIVE(T:3.0)

21441-13A00-000  

21441-13A01-000
 2144113A00000

Unit Price

8
PLATE, CLUTCH DRIVE

21441-19A00-000  

21441-25C01-000
 2144119A00000

Unit Price

9
PLATE,CLUTCH DRIVEN<br />PLATE, DRIVEN (T:1.6)
PLATE, CLUTCH DRIVEN
PLATE, DRIVEN (T:1.6)

21451-19A00-000   2145119A00000

2145119A00000

Unit Price

10
PLATE, CLUTCH DRIVEN(T:2.0)
PLATE, DRIVEN (T:2.0)

21451-36200-000   2145136200000

2145136200000

Unit Price

11
DISCONTINUE
SEAT, WAVE WASHER

21471-36200-000   2147136200000

2147136200000
Not available
12
RING, STOPPER
STOPPER RING

21481-39301-000   2148139301000

2148139301000

Unit Price

13
WASHER
WAVE WASHER

09164-98001-000   0916498001000

0916498001000
Not available
14
DISCONTINUE

21462-04A00-000  

2146204A00000
Not available
14
21462-32C50
DISCONTINUED

21462-19A10-000   2146219A10000

2146219A10000
Not available
15
SPRING

09440-15024-000  

09440-15030-000
 0944015024000

Unit Price

15
DISCONTINUE
SPRING

09440-15020-000   0944015020000

0944015020000
Not available
16
BOLT, 5X16

09116-05003-000  

09116-05020-000
 0911605003000

Unit Price

17
DISCONTINUE
RACK, CLUTCH RELEASE

23165-13A00-000   2316513A00000

2316513A00000
Not available
18
PINION, CLUTCH RELEASE
PINION

23261-13A01-000   2326113A01000

2326113A01000

Unit Price

19
WASHER(12.5X17X1)

09160-12035-000  

09160-12086-000
 0916012035000

Unit Price

20
RD SFT ARM PIN BRG
BEARING

09263-10002-000   0926310002000

0926310002000

Unit Price

21
OIL SEAL<br />OIL SEAL (10X17X5)
OIL SEAL
OIL SEAL (10X17X5)

09285-10004-000   0928510004000

0928510004000

Unit Price

22
ARM, CLUTCH RELEASE

23271-14101-000  

23271-14103-000
 2327114101000

Unit Price

23
BOLT

01107-06166-000  

01107-06163-000
 0110706166000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CLUTCH (MODEL F/G) of your Suzuki of QUADRACER. Let us know if you have any questions.

Genuine parts for Suzuki 250 QUADRACER 1990
