FRONT FINAL GEAR

DIFFERENTIAL LOCK FOR SUZUKI KINGQUAD 300 1991

TRANSMISSION LEVER

Item numbers
DIFFERENTIAL LOCK Suzuki QUAD 300 KINGQUAD 1991 LT-F4WDXM(E28)
2
2
2
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
16
1
FORK, DIFF LOCKING SHIFT
FORK, DIFFRENTIAL LOCKING

27941-19B00-000   2794119B00000

2794119B00000
Not available
2
SHAFT, GEAR SHIFT FORK

25421-14300-000  

25421-14301-000
 2542114300000

Unit Price

3
DISCONTINUE
CAM, DIFFERENTIAL LOCKING

27911-19B01-000   2791119B01000

2791119B01000
Not available
4
SHAFT, FR DIFF LOCKING CAM
SHAFT, CAM

27921-19B01-000   2792119B01000

2792119B01000

Unit Price

5
SPRING

09440-17008-000   0944017008000

0944017008000

Unit Price

6
SHIM(10X18X1)

08211-10181-000  

09181-10167-000
 0821110181000

Unit Price

7
TOP PINION WASHER<br />WASHER
TOP PINION WASHER
WASHER

08211-12241-000   0821112241000

0821112241000

Unit Price

8
OIL SEAL<br />OIL SEAL (12X22X9)
OIL SEAL
OIL SEAL (12X22X9)

09285-12006-000   0928512006000

0928512006000

Unit Price

9
STOPPER, GEAR SHIFT CAM

25351-18000-000  

25351-39300-000
 2535118000000

Unit Price

10
HOUSING, GEAR SHIFT CAM STOPPER
HOUSING

25352-11010-000   2535211010000

2535211010000

Unit Price

11
SPRING

09440-05035-000   0944005035000

0944005035000

Unit Price

12
GASKET,13.8X18.8X0.4<br />GASKET
GASKET, 13.8X18.8X0.4
GASKET

09168-14002-000   0916814002000

0916814002000

Unit Price

13
ARM, T/M GEAR SHIFT
ARM, DIFFERENTIAL LOCKING

25360-19B00-000   2536019B00000

2536019B00000

Unit Price

14
BOLT
BOLT

01500-06207-000   0150006207000

0150006207000

Unit Price

15
WASHER
WASHER

08322-01087-000   0832201087000

0832201087000

Unit Price

16
E RING

08332-11063-000  

08332-1106B-000
 0833211063000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the DIFFERENTIAL LOCK of your Suzuki of KINGQUAD. Let us know if you have any questions.

Genuine parts for Suzuki 300 KINGQUAD 1991

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 300 KINGQUAD 1991

Select your Suzuki 1991 model

300 KINGQUAD 1991 LT-F4WDXM(E28)

Suzuki KINGQUAD

Displacement: 300 cc
Year: 1991
Model code LT-F4WDXM(E28)
