STARTER MOTOR (MODEL Y / K1 / K2 / K4)

IGNITION FOR SUZUKI KINGQUAD 300 2000

ELECTRICAL

Item numbers
IGNITION Suzuki QUAD 300 KINGQUAD 2000 LT-F300FY(E24)
1
1
2
2
3
4A
4
5
6
7
8
9
1
STATOR ASSY

32101-19B10-000  

32101-19B30-000
 3210119B10000

Unit Price

2
ROTOR ASSY

32102-19B30-000   3210219B30000

3210219B30000

Unit Price

2
DISCONTINUE
ROTOR ASSY

32102-19B20-000   3210219B20000

3210219B20000
Not available
3
BOLT

01547-06253-000  

01547-0625B-000
 0154706253000

Unit Price

4
BOLT (5X10)

09100-05019-000   0910005019000

0910005019000

Unit Price

4A
BOLT

07130-05103-000   0713005103000

0713005103000
Not available
5
NUT, MAGNETO ROTOR
NUT

31792-18A00-000   3179218A00000

3179218A00000

Unit Price

6
KEY
KEY

09420-04008-000   0942004008000

0942004008000

Unit Price

7
PLATE, MAGNETO
PLATE

32373-19B00-000   3237319B00000

3237319B00000

Unit Price

8
BOLT

01547-06123-000  

01547-0612B-000
 0154706123000

Unit Price

9
SHEET, HEAT PROTECTION

37841-22D00-000   3784122D00000

3784122D00000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the IGNITION of your Suzuki of KINGQUAD. Let us know if you have any questions.

Genuine parts for Suzuki 300 KINGQUAD 2000

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 300 KINGQUAD 2000

Select your Suzuki 2000 model

300 KINGQUAD 2000 LT-F300FY(E24)

Suzuki KINGQUAD

Displacement: 300 cc
Year: 2000
Model code LT-F300FY(E24)
4WD
