STEERING LINKAGE - HUB (MODEL X / Y / K1) REFER TO FIG.49A(H-6) FOR MODEL K2/K4

STEERING LINKAGE - HUB (MODEL K2 / K4) FOR SUZUKI KINGQUAD 300 2001

FRONT WHEEL (MODEL X / Y / K1) REFER TO FIG.50A(H-8) FOR MODEL K2/K4

Item numbers

TIE ROD, STEERING

51281-22A00-000 5128122A00000

$24,97

Unit Price

KNUCKLE, STEERING, R
KNUCKLE, STEERING RH

51231-39D10-000 5123139D10000

$301,97

Unit Price

KNUCKLE, STEERING, L
KNUCKLE, STEERING LH

51241-39D10-000 5124139D10000

$420,97

Unit Price

END, KNUCKLE STEERING

51220-19A02-000

51220-19A03-000

$96,97

Unit Price

END, ROD(THREAD), R
ROD END (RH THREAD)

51260-19B02-000 5126019B02000

$85,97

Unit Price

END, ROD, L

51270-41B01-000

51270-38F10-000

$106,97

Unit Price

NUT
NUT, TIE ROD (RH THREAD)

09140-10043-000 0914010043000

$3,97

Unit Price

NUT

08319-21103-000

08319-2110B-000

$3,97

Unit Price

NUT, TIE ROD LH
NUT, TIE ROD (LH THREAD)

09140-10027-000 0914010027000

$2,97

Unit Price

WASHER, 10.2X18.5X1.8
LOCK WASHER, ROD END

09162-10008-000 0916210008000

$5,97

Unit Price

04111-20208-000

04111-2020A-000

$2,97

Unit Price

04111-20208-000

04111-2020A-000

$2,97

Unit Price

STOPPER, KNUCKLE END BOLT

52418-24500-000 5241824500000

$14,97

Unit Price

BOLT(14X38)
BOLT, KNUCKLE END UPPER (14X38)

09103-14009-000 0910314009000

$20,97

Unit Price

BOLT 14X30
BOLT, KNUCKLE END LOWER (14X30)

09103-14008-000 0910314008000

$53,97

Unit Price

WASHER, LOCK

08321-01103-000

08321-0110B-000

$3,97

Unit Price

BOLT, KNUCKLE(10X30)
BOLT, KNUCKLE (10X32)

51233-09F00-000 5123309F00000

$8,97

Unit Price

WASHER(14.5X28X0.8)
WASHER, KNUCKLE END LOWER

09160-14060-000 0916014060000

$5,97

Unit Price

ARM, KNUCKLE STEERING, R
ARM, KNUCKLE STEERING RH

51232-39D00-000 5123239D00000

$252,97

Unit Price

ARM, KNUCKLE STEERING, L
ARM, KNUCKLE STEERING LH

51242-39D00-000 5124239D00000

$271,97

Unit Price

BOLT(10X37)
BOLT, ARM STEERING NO.1 (10X37)

09111-10040-000 0911110040000

$14,97

Unit Price

BOLT

01550-08303-000

01550-0830B-000

$4,97

Unit Price

BOLT(10X29)
BOLT, ARM KNUCKLE TIE-ROD END (10X29)

09100-10262-000 0910010262000

$5,97

Unit Price

SPACER, HUB BEARING

54731-19B00-000 5473119B00000

$18,97

Unit Price

SEAL
DUST SEAL, INNER (38X55X8)

09283-38012-000 0928338012000

$22,97

Unit Price

SEAL, RR AXLE HSG
DUST SEAL, OUTER (38X55X6.4)

09283-38022-000 0928338022000

$20,97

Unit Price

BEARING

08123-60067-000 0812360067000

$36,97

Unit Price

PROTECTOR SET, R

54903-38F10-000

54900-38810-000

$36,97

Unit Price

PROTECTOR SET, L

54904-38F10-000

54900-38820-000

$36,97

Unit Price

BOLT

01550-06123-000

01550-0612B-000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STEERING LINKAGE - HUB (MODEL K2/K4) of your Suzuki of KINGQUAD. Let us know if you have any questions.
