Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

REAR FEDNER (SANS E24)

REAR FEDNER (DR-Z400E E24) FOR SUZUKI DR-Z 400 2004

LABEL (MODELE K2 / K3 / K4)

Item numbers
REAR FEDNER (DR-Z400E E24) Suzuki MOTO 400 DR-Z 2004 DR-Z400EK4(E24)
1
2
3
4
4
5
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
1
FENDER, RR

63113-29F40-YU1  

63113-29FA0-YU1
 6311329F40YU1

Unit Price

2
BOLT<br />BOLT, FRONT
BOLT
BOLT, FRONT

09111-06066-000   0911106066000

0911106066000

Unit Price

3
PLATE, RR FENDER

63312-13E00-000  

63312-13E01-000
 6331213E00000

Unit Price

4
BOLT,6X20,W/PL WASHE<br />BOLT
BOLT, 6X20, W/PL WASHE
BOLT

09116-06115-000   0911606115000

0911606115000

Unit Price

5
WASHER

09169-06073-000   0916906073000

0916906073000

Unit Price

6
EXTENSION, REAR FENDER

63311-29F40-000   6331129F40000

6331129F40000
Not available
7
NUT,COWL<br />NUT, FITTING
NUT, COWL
NUT, FITTING

94484-24F00-000   9448424F00000

9448424F00000

Unit Price

8
BOLT

01550-05123-000  

01550-0512B-000
 0155005123000

Unit Price

9
WASHER

09169-05021-000  

09169-05024-000
 0916905021000

Unit Price

10
MUDGUARD, RR FENDER FR
MUDGUARD, FRONT

63411-29F00-000   6341129F00000

6341129F00000

Unit Price

11
BOLT

01547-06163-000  

01547-0616B-000
 0154706163000

Unit Price

12
WASHER

09169-06045-000   0916906045000

0916906045000

Unit Price

13
LOCK SET, HELMET

95700-44810-000   9570044810000

9570044810000
Not available
14
SCREW
SCREW

09139-06089-000   0913906089000

0913906089000

Unit Price

15
TOOL ASSY

09800-21042-000  

09800-21092-000
 0980021042000

Unit Price

16
BAND
BAND, TOOL

09462-00008-000  

0946200008000
Not available
17
MUDGUARD, RR FENDER, R
MUDGUARD, REAR FENDER RH

63114-29F00-000   6311429F00000

6311429F00000

Unit Price

18
BOLT
BOLT, LOWER

09111-06081-000   0911106081000

0911106081000

Unit Price

19
BOLT,6X12
BOLT, 6X12

63161-43E00-000  

09111-06107-000
 6316143E00000

Unit Price

20
BAG ASSY, SEAT TAIL

94900-29FA0-000  

94900-29FA1-000
 9490029FA0000

Unit Price

21
CUSHION, REAR BAG
CUSHION

94915-44E00-000   9491544E00000

9491544E00000

Unit Price

22
BOLT

01550-06203-000  

01550-0620B-000
 0155006203000

Unit Price

23
WASHER

09169-06063-000   0916906063000

0916906063000

Unit Price

24
NUT, ROOF RAIL
NUT

09159-06078-000   0915906078000

0915906078000

Unit Price

25
SEALER, SIDE COVER L
CUSHION, FRONT

47161-29B00-000   4716129B00000

4716129B00000

Unit Price

26
PROTECTOR(170X95X3.0)<br />CUSHION, REAR
PROTECTOR(170X95X3.0)
CUSHION, REAR

33651-37000-000   3365137000000

3365137000000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for Suzuki 400 DR-Z 2004

BODY/FRAME ELECTRICAL ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS

Suzuki 400 DR-Z 2004

Choose your Suzuki 400 2004 DR-Z model

400 DR-Z 2004 DR-Z400EK4(E24)

Suzuki DR-Z

Displacement: 400 cc
Year: 2004
Model code DR-Z400EK4(E24)
