CARBURETOR FOR SUZUKI GSX 400 1982

AIR FILTER

CARBURETOR, LH

13201-44230-000 1320144230000

Not available

CARBURETOR, RH

13202-44230-000 1320244230000

Not available

DISCONTINUED

13551-44010-000 1355144010000

Not available

SCREW

13604-44080-000 1360444080000

$6,97

Unit Price

DIAPHRAGM

13500-44230-000 1350044230000

Not available

SPRING

13503-44200-000 1350344200000

Not available

DISCONTINUED

13601-03078-000 1360103078000

Not available

PLATE

13581-44200-000 1358144200000

Not available

COVER, DIAPHRAGM

13502-44230-000 1350244230000

Not available

O RING

13278-47090-000

13278-47091-000

$3,97

Unit Price

CAP, STARTER VALVE
CAP

13682-31210-000 1368231210000

$6,97

Unit Price

SHAFT

13550-44210-000 1355044210000

Not available

SHAFT

13550-44220-000 1355044220000

Not available

BRACKET

13627-44230-000 1362744230000

Not available

SPRING

13573-44210-000 1357344210000

Not available

SEAL, THRO SHAFT

13651-51010-000

13651-51011-000

$6,97

Unit Price

GASKET, THROTTLE SHAFT
GASKET

13557-47070-000 1355747070000

$7,97

Unit Price

E RING

13617-44080-000 1361744080000

$5,97

Unit Price

CAP

13578-47070-000 1357847070000

$9,97

Unit Price

NUT

13607-47070-000 1360747070000

$5,97

Unit Price

SCREW

13605-47080-000 1360547080000

$9,97

Unit Price

13563-44110-000 1356344110000

Not available

DISCONTINUED

13268-44100-000 1326844100000

Not available

PLUG, NEEDLE JET
PLUG

13357-44080-000 1335744080000

$8,97

Unit Price

GASKET, FLOAT CHAMBER

13251-44080-000

13251-44081-H17

$18,97

Unit Price

JET, PILOT (42.5)

09492-42011-000 0949242011000

Not available

DISCONTINUE
JET, NEEDLE (P-1)

09494-00312-000 0949400312000

Not available

SCREW, PILOT

13279-47080-000

13279-47070-000

$19,97

Unit Price

.O RING

13278-44080-000 1327844080000

Not available

.WASHER

13277-44080-000 1327744080000

Not available

SPRING

13268-47070-000 1326847070000

$6,97

Unit Price

WASHER

13332-44080-000

13382-03110-000

$4,97

Unit Price

.JET, MAIN (120)

09491-24005-000 0949124005000

Not available

GASKET

13246-44080-000 1324644080000

$6,97

Unit Price

PLUG, DRAIN
SCREW, GUIDE

13247-44080-000 1324744080000

$16,97

Unit Price

SCREW

02112-04068-000

02112-0406B-000

$2,97

Unit Price

PLATE, NEEDLE VALVE FITING
PLATE

13373-11400-000 1337311400000

$22,97

Unit Price

FLOAT

13250-44080-000 1325044080000

$45,97

Unit Price

PIN, FLOAT
PIN

13254-92311-000 1325492311000

$3,97

Unit Price

.NEEDLE VALVE ASSY

13370-11400-000 1337011400000

Not available

RING

13387-47010-000 1338747010000

$11,97

Unit Price

DISCONTINUED

13384-45010-000 1338445010000

Not available

PIN, FLOAT
GASKET

13254-20010-000 1325420010000

$5,97

Unit Price

SPRING, NEEDLE JET
SPRING

13388-47010-000 1338847010000

$13,97

Unit Price

NEEDLE, JET (5069-4)

13383-44200-000 1338344200000

Not available

.FILTER

13376-65010-000 1337665010000

Not available

O RING, NEEDLE VALVE SEAT

13374-44080-000

13374-35C00-000

$7,97

Unit Price

SCREW

02112-05168-000

02112-05167-000

$2,97

Unit Price

WASHER, LOCK

08321-21058-000

08321-0105A-000

$2,97

Unit Price

.SCREW

02112-05108-000 0211205108000

Not available

SCREW, INTAKE PORT

02112-05088-000 0211205088000

Not available

.SCREW

13605-45410-000 1360545410000

Not available

DISCONTINUE
REORDER ROBINSONS MOTORS

09493-25001-000 0949325001000

Not available

RING

13387-44200-000 1338744200000

Not available

SPRING

13573-44200-000 1357344200000

Not available

RING

13387-44210-000 1338744210000

Not available

FLANGE ASSY

13210-44230-000 1321044230000

Not available

SHAFT, STARTER

13410-11400-000 1341011400000

Not available

SCREW

02112-06128-000

02112-06127-000

$3,97

Unit Price

DISCONTINUE
SCREW

13605-47070-000 1360547070000

Not available

LEVER

13422-44080-000 1342244080000

Not available

DISCONTINUED

13687-02500-000 1368702500000

Not available

SCREW

02112-05128-000

02112-05127-000

$3,97

Unit Price

SCREW, INTAKE PORT

02112-05088-000 0211205088000

Not available

WASHER, LOCK

08321-21058-000

08321-0105A-000

$2,97

Unit Price

SPRING, THROTTLE SCREW

13271-44220-000

13268-37420-000

$5,97

Unit Price

BRACKET

13621-44210-000 1362144210000

Not available

CAP

13681-16600-000

13681-16601-000

$16,97

Unit Price

NIPPLE

13685-11400-000 1368511400000

Not available

DISCONTINUE
ADJUSTER

13267-47070-000 1326747070000

Not available

DISCONTINUED

13687-44230-000 1368744230000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CARBURETOR of your Suzuki of GSX. Let us know if you have any questions.
