INDICATORS (E22, E25)

TAIL LIGHT FOR SUZUKI GSX 400 1983

TAIL LIGHT (E22, E25)

LAMP UNIT, REAR COMBINATION

35720-45210-000 3572045210000

Not available

LAMP UNIT, REAR COMBINATION

35720-45221-000 3572045221000

Not available

LAMP UNIT, REAR COMBINATION

35720-45271-000 3572045271000

Not available

DISCONTINUE
LENS

35712-45013-000 3571245013000

Not available

LENS

35712-45070-000 3571245070000

Not available

LENS

35712-45613-000 3571245613000

Not available

DISCONTINUE
GASKET

35713-45010-000 3571345010000

Not available

BULB(12V21/5W)
BULB

09471-12046-000 0947112046000

$16,97

Unit Price

BULB (12V, 23/8W)

09471-12038-000 0947112038000

Not available

SCREW

09125-04002-000

02112-04558-000

$2,97

Unit Price

GASKET

35627-43010-000 3562743010000

$3,97

Unit Price

SCREW

02112-06128-000

02112-06127-000

$3,97

Unit Price

WASHER

08322-21068-000 0832221068000

Not available

LOCK WASHER

08321-21068-000 0832121068000

Not available

NUT FIG.42 (H-4) : E16, E18, E22,

08310-11068-000 0831011068000

Not available

BRACKET ASSY

35730-44720-000 3573044720000

Not available

BRACKET ASSY

35730-44740-000 3573044740000

Not available

CUSHION

35765-22210-000 3576522210000

$7,97

Unit Price

CUSHION

35765-11900-000 3576511900000

Not available

DISCONTINUE
SPACER

35766-37120-000 3576637120000

Not available

SPACER

35766-11900-000 3576611900000

Not available

BOLT, RETURN

01107-06258-000 0110706258000

Not available

WASHER 6.5X10X1.2

09160-06027-000

09160-06077-000

$3,97

Unit Price

WASHER

08322-21068-000 0832221068000

Not available

NUT FIG.42 (H-4) : E16, E18, E22,

08310-11068-000 0831011068000

Not available

GROMMET, LEAD WIRE

09308-07004-000 0930807004000

Not available

DISCONTINUE
REFLEX REFLECTOR, REAR

35970-49030-000 3597049030000

Not available

WASHER, LOCK

08321-21058-000

08321-0105A-000

$2,97

Unit Price

NUT

08310-11058-000

08310-00057-000

$3,97

Unit Price

BRACKET

35974-44290-000 3597444290000

Not available

BOLT (5*10)

01104-05108-000 0110405108000

Not available

LOCK WASHER

08322-21058-000 0832221058000

Not available

NUT

08310-11058-000

08310-00057-000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the TAIL LIGHT of your Suzuki of GSX. Let us know if you have any questions.
