Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

HANDELBAR (AN400SK5 / SK6)

HANDGRIPS - LEVERS FOR SUZUKI BURGMAN 400 2005

FRONT WHEEL

Item numbers
HANDGRIPS - LEVERS Suzuki SCOOTER 400 BURGMAN 2005 AN400S K5 (E02,E19)
1
2
3
4
4
5
6
7
8
9
10
10
11
12
13
14
15
16
17
18
19
20
21
22
22
23
24
25
25
1
GRIP,THROTTLE
GRIP, THROTTLE

57110-46E01-000  

57110-46E02-000
 5711046E01000

Unit Price

2
LEVER, FR BRAKE
LEVER, FRONT BRAKE

57421-14F00-000   5742114F00000

5742114F00000

Unit Price

3
BOLT, BRAKE LEVER PIVOT
BOLT, PIVOT

57431-04F00-000   5743104F00000

5743104F00000

Unit Price

4
NUT, LEVER PIVOT
NUT, PIVOT

57433-09F00-000   5743309F00000

5743309F00000

Unit Price

5
SWITCH ASSY, STOP

57460-14J00-000  

57460-14J02-000
 5746014J00000

Unit Price

6
SCREW,WITH WASHER(4X12)<br />.SCREW
SCREW, WITH WASHER(4X12)
.SCREW

57465-17C00-000   5746517C00000

5746517C00000

Unit Price

7
GRIP, L(BLACK)

57211-22D01-000  

57211-22D02-291
 5721122D01000

Unit Price

8
LEVER ASSY, RR BRAKE
LEVER ASSY, REAR BRAKE

57500-14F00-000   5750014F00000

5750014F00000

Unit Price

9
BOLT, BRAKE LEVER PIVOT
.BOLT, PIVOT

57431-04F00-000   5743104F00000

5743104F00000

Unit Price

10
NUT

08319-21063-000  

08319-2106A-000
 0831921063000

Unit Price

11
SWITCH ASSY, RR BRAKE

57560-14J00-000  

57560-14J02-000
 5756014J00000

Unit Price

12
DISCONTINUE
LEVER ASSY, BRAKE LOCK

57810-14G01-000   5781014G01000

5781014G01000
Not available
13
SWITCH ASSY, RR BRAKE

57560-14F11-000  

57560-14J02-000
 5756014F11000

Unit Price

14
SCREW, BRAKE LOCK SWITCH
SCREW, SWITCH

57852-10G00-000   5785210G00000

5785210G00000

Unit Price

15
NUT
NUT, KNOB

57853-10G00-000   5785310G00000

5785310G00000

Unit Price

16
KNOB, BRAKE LOCK

57820-14G00-000   5782014G00000

5782014G00000

Unit Price

17
SCREW

02112-04103-000  

02112-0410A-000
 0211204103000

Unit Price

18
01550-0616A
BOLT

01550-06163-000  

0155006163000
Not available
19
CABLE, BRAKE LOCK

58810-14G00-000   5881014G00000

5881014G00000

Unit Price

20
PLATE, LEVER SEAL

57950-14G00-000   5795014G00000

5795014G00000

Unit Price

21
SCREW

03512-05123-000  

03511-0512B-000
 0351205123000

Unit Price

22
PROTECTOR, STRTR CABL
CLAMP

09403-14204-000  

0940314204000
Not available
23
BOLT

01550-06123-000  

01550-0612B-000
 0155006123000

Unit Price

24
BOLT

09119-06105-000   0911906105000

0911906105000

Unit Price

25
CLAMP

09403-20403-000   0940320403000

0940320403000

Unit Price

25
CLAMP

09403-25401-000   0940325401000

0940325401000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the HANDGRIPS - LEVERS of your Suzuki BURGMAN 400 of BURGMAN. Let us know if you have any questions.

Genuine parts for Suzuki 400 BURGMAN 2005

BODY/FRAME ELECTRICAL ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 400 BURGMAN 2005

Select your Suzuki 2005 model

400 BURGMAN 2005 AN400S K5 (E02,E19)

BURGMAN 400

Suzuki BURGMAN

Displacement: 400 cc
Year: 2005
Model code AN400S K5 (E02,E19)
