WIRING HARNESS (AN400AL2 E24)

WIRING HARNESS (AN400ZAL2 E02) FOR SUZUKI BURGMAN 400 2012

WIRING HARNESS (AN400ZAL2 E19)

Item numbers

WIRING HARNESS

36610-05HL0-000 3661005HL0000

Not available

COVER
.BOOT

36618-21E00-000 3661821E00000

$15,97

Unit Price

.FUSE (10A)

09481-10501-000

Not available

.FUSE (15A)

09481-15501-000 0948115501000

$2,97

Unit Price

RECTIFIER ASSY
.DIODE

32800-16A00-000 3280016A00000

$28,97

Unit Price

CLAMP(L:63)
CLAMP, WIRING HARNESS

36651-48E00-000 3665148E00000

$4,97

Unit Price

CAP, TS

36654-06J20-000

36654-06J21-000

$18,97

Unit Price

BRACKET, LEAD WIRE

36672-05H10-000 3667205H10000

$6,97

Unit Price

CLAMP(L:65)

09404-06429-000

09404-06039-000

$3,97

Unit Price

CLAMP
CLAMP (L:90)

09407-11402-000 0940711402000

$2,97

Unit Price

BAND, WIRING HARNESS
CLAMP (L:125)

09407-14403-000 0940714403000

$3,97

Unit Price

CLAMP
CLAMP (L:145)

09407-14407-000 0940714407000

$4,97

Unit Price

CLAMP

09407-19401-000

09407-22403-000

$3,97

Unit Price

CLAMP
CLAMP (L:235)

09407-25401-000 0940725401000

$7,97

Unit Price

BOLT

01547-0612A-000 015470612A000

$3,97

Unit Price

SCREW

03541-0616A-000 035410616A000

$3,97

Unit Price

SOCKET ASSY
TERMINAL, POWER SOURCE (GRAY)

39410-76F00-P4Z 3941076F00P4Z

$60,97

Unit Price

COVER
.COVER (GRAY)

39441-76F00-P4Z 3944176F00P4Z

$15,97

Unit Price

LOCK ASSY, STEERING SET

37120-14850-000 3712014850000

Not available

.SWITCH, IGNITION

37111-10G00-000 3711110G00000

$86,97

Unit Price

.SCREW, IGNITION SWITCH PLATE

37121-06H00-000 3712106H00000

$12,97

Unit Price

.PLATE, IGNITION SWITCH

37181-06H00-000 3718106H00000

$20,97

Unit Price

SHUTTER SET

37155-11810-000 3715511810000

Not available

LOCK SET

37101-14861-000 3710114861000

Not available

SCREW (6X20)

09139-06048-000 0913906048000

$2,97

Unit Price

WASHER
WASHER (6.5X18X1.6)

09160-06109-000 0916006109000

$3,97

Unit Price

NUT

08316-1006B-000 083161006B000

$3,97

Unit Price

37840-11X52

37840-11X50-000

Not available

BOLT

01550-0620A-000 015500620A000

$2,97

Unit Price

RELAY ASSY, SIDE STAND

38740-26E00-000

38740-26E01-000

$39,97

Unit Price

RELAY ASSY, SIDE STAND

38740-26E00-000

38740-26E01-000

$39,97

Unit Price

HORN ASSY

38500-05H00-000 3850005H00000

$88,97

Unit Price

BOLT

01550-0812A-000

01550-0812B-000

$4,97

Unit Price

LAMP ASSY, TRUNK BOX

36210-14G00-000 3621014G00000

$189,97

Unit Price

.LENS, ROOM LAMP

36212-79001-000 3621279001000

Not available

BULB(12V45/45W, STANLEY, 70281A)
.BULB (12V5W)

09471-12073-000

Not available

SCREW

03541-0412B-000 035410412B000

$2,97

Unit Price

SWITCH ASSY, TRUNK BOX LAMP

37980-14F00-000 3798014F00000

$115,97

Unit Price

BOLT

07130-0516B-000 071300516B000

$4,97

Unit Price

WIRE, POWER SOURCE LEAD

36852-05H00-000

36852-05H01-000

$20,97

Unit Price

DISCONTINUE
WIRE, SPEED SENSOR

36853-05H00-000

Not available

WIRE, IGNITION COIL
WIRE, IGNITION COIL LEAD

36854-05H30-000

Not available

WIRE, IGNITION SW LEAD

36854-05H10-000 3685405H10000

Not available

WIRE, ABS CONT LEAD

36859-05H00-000

Not available

SENSOR, AIR TEMP
SENSOR, AMBIENT AIR

95643-58J00-000 9564358J00000

$22,85

Unit Price

PROTECTOR(80X80X2)

33652-38A10-000

33652-07D00-000

$11,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the WIRING HARNESS (AN400ZAL2 E02) of your Suzuki BURGMAN 400 of BURGMAN. Let us know if you have any questions.
