CLUTCH

TRANSMISSION FOR SUZUKI GS-S 450 1987

GEAR SHIFTING ASSY

TRANSMISSION Suzuki MOTO 450 GS-S 1987 GS450SH(E/F/G/H/J)
1
COUNTERSHAFT ASSY

24120-44100-000   2412044100000

2412044100000
Not available
2
.COUNTERSHAFT (NT:13)

24121-44100-000   2412144100000

2412144100000
Not available
3
GEAR, 2ND DRIVE (NT:18)

24221-44001-000   2422144001000

2422144001000

Unit Price

4
GEAR, 3/4 DRIVE (NT:21/24)

24231-44001-000   2423144001000

2423144001000
Not available
5
GEAR, 5TH DRIVE (NT:26)

24250-44001-000   2425044001000

2425044001000
Not available
6
GEAR, 6TH DRIVE (NT:27)

24260-44000-000   2426044000000

2426044000000
Not available
7
WASHER, 5TH DRIVE GEA

08211-25341-000  

09181-25167-000
 0821125341000

Unit Price

8
DRIVEN GEAR CIRCLIP
CIRCLIP

09380-25010-000   0938025010000

0938025010000

Unit Price

9
BEARING(25X62X17)<br />BALL BEARING (25X62X17)
BEARING(25X62X17)
BALL BEARING (25X62X17)

09262-25051-000   0926225051000

0926225051000

Unit Price

10
C-RING

09390-62006-000  

09390-62012-000
 0939062006000

Unit Price

11
BEARING, LH

09263-20026-000   0926320026000

0926320026000
Not available
12
PIN 7 X 12<br />PIN
PIN 7 X 12
PIN

04221-07129-000   0422107129000

0422107129000

Unit Price

13
PLATE, COUNTERSHAFT BEARING
HOLDER, BEARING

24741-44102-000   2474144102000

2474144102000

Unit Price

14
SCREW 6X16<br />SCREW
SCREW 6X16
SCREW

02122-06167-000   0212206167000

0212206167000

Unit Price

15
DRIVESHAFT

24100-44811-000   2410044811000

2410044811000
Not available
16
GEAR, 1ST DRIVEN

24310-44000-000  

24310-44001-000
 2431044000000

Unit Price

17
WASHER
WASHER

08211-20341-000   0821120341000

0821120341000

Unit Price

18
GEAR, 2ND DRIVEN.NT:32)

24321-44004-000  

24321-20F01-000
 2432144004000

Unit Price

19
BUSH

09301-25001-000  

24322-19F00-000
 0930125001000

Unit Price

20
DRIVEN GEAR CIRCLIP
CIRCLIP

09380-25010-000   0938025010000

0938025010000

Unit Price

21
GEAR, 3RD DRIVEN

24331-44002-000  

24331-44003-000
 2433144002000

Unit Price

22
WASHER
WASHER

09167-25012-000   0916725012000

0916725012000

Unit Price

23
LOCK WASHER
LOCK WASHER

09167-25013-000   0916725013000

0916725013000

Unit Price

24
DRIVEN GEAR CIRCLIP
CIRCLIP

09380-25010-000   0938025010000

0938025010000

Unit Price

25
GEAR, 4TH DRIVEN

24341-44002-000  

24341-44003-000
 2434144002000

Unit Price

26
WASHER
WASHER

09167-25012-000   0916725012000

0916725012000

Unit Price

27
LOCK WASHER
LOCK WASHER

09169-25001-000   0916925001000

0916925001000

Unit Price

28
DRIVEN GEAR CIRCLIP
CIRCLIP

09380-25010-000   0938025010000

0938025010000

Unit Price

29
DISCONTINUE
GEAR, 5TH DRIVEN (NT:25)

24351-44001-000   2435144001000

2435144001000
Not available
30
GEAR, 6TH DRIVEN(NT:23)

24361-44002-000  

24361-44010-000
 2436144002000

Unit Price

31
C-RING

09390-62006-000  

09390-62012-000
 0939062006000

Unit Price

32
OIL SEAL
OIL SEAL (32*62*7)

09283-32015-000   0928332015000

0928332015000

Unit Price

33
BEARING(20X34X17)

09263-20028-000  

09263-20027-000
 0926320028000

Unit Price

34
OIL SEAL

09282-32002-000   0928232002000

0928232002000

Unit Price

35
DISCONTINUE
SPROCKET, ENGINE (NT:16)

27511-44000-000   2751144000000

2751144000000
Not available
36
DISCONTINUE
NUT

09140-20009-000   0914020009000

0914020009000
Not available
37
WASHER, LOCK

09167-25011-000  

09167-25019-000
 0916725011000

Unit Price

38
DISCONTINUE

27600-44430-000  

2760044430000
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the TRANSMISSION of your Suzuki of GS-S. Let us know if you have any questions.
