TIMING (MODEL D)

CARBURETOR (MODEL Z) FOR SUZUKI GS 450 1982

CARBURETOR (MODEL D)

CARBURETOR (MODEL Z) Suzuki MOTO 450 GS 1982 GS450Z(2/Z/D)
1
CARBURETOR ASSY, LH

13201-44410-000   1320144410000

1320144410000
Not available
2
CARBURETOR ASSY, RH

13202-44410-000   1320244410000

1320244410000
Not available
3
VALVE, THROTTLE

13551-44410-000   1355144410000

1355144410000
Not available
4
SCREW
SCREW

13604-44080-000   1360444080000

1360444080000

Unit Price

5
SCREW, PILOT

13279-47080-000  

13279-47070-000
 1327947080000

Unit Price

6
.O RING

13278-44080-000   1327844080000

1327844080000
Not available
7
.WASHER

13277-44080-000   1327744080000

1327744080000
Not available
8
SPRING
SPRING

13268-47070-000   1326847070000

1326847070000

Unit Price

9
DISCONTINUE
DIAPHRAGM ASSY

13500-38310-000  

1350038310000
Not available
10
REORDER BRAN BARDSLEY

13503-44400-000   1350344400000

1350344400000
Not available
11
DISCONTINUE<br />CLIP
DISCONTINUE
CLIP

13581-44030-000   1358144030000

1358144030000
Not available
12
DISCONTINUE<br />HOLDER, GUIDE
DISCONTINUE
HOLDER, GUIDE

13389-44030-000   1338944030000

1338944030000
Not available
13
COVER

13502-38300-000   1350238300000

1350238300000
Not available
14
SCREW

02112-05168-000  

02112-05167-000
 0211205168000

Unit Price

15
WASHER, LOCK

08321-21058-000  

08321-0105A-000
 0832121058000

Unit Price

16
SHAFT

13550-44210-000   1355044210000

1355044210000
Not available
17
SHAFT

13550-44220-000   1355044220000

1355044220000
Not available
18
BRACKET

13621-44400-000   1362144400000

1362144400000
Not available
19
SPRING

13573-44210-000   1357344210000

1357344210000
Not available
20
SEAL,THRO SHAFT
SEAL, THRO SHAFT

13651-51010-000  

13651-51011-000
 1365151010000

Unit Price

21
GASKET,THROTTLE SHAFT<br />PACKING
GASKET, THROTTLE SHAFT
PACKING

13557-47070-000   1355747070000

1355747070000

Unit Price

22
E RING
E RING

13617-44080-000   1361744080000

1361744080000

Unit Price

23
CAP
CAP

13578-47070-000   1357847070000

1357847070000

Unit Price

24
SPRING

13268-44110-000   1326844110000

1326844110000
Not available
25
PIN

13563-44110-000   1356344110000

1356344110000
Not available
26
NUT
NUT

13607-47070-000   1360747070000

1360747070000

Unit Price

27
SCREW
SCREW

13605-47080-000   1360547080000

1360547080000

Unit Price

28
O RING
O RING

13278-47090-000  

13278-47091-000
 1327847090000

Unit Price

29
CAP,STARTER VALVE<br />CAP
CAP, STARTER VALVE
CAP

13682-31210-000   1368231210000

1368231210000

Unit Price

30
GASKET, FLOAT CHAMBER

13251-44080-000  

13251-44081-H17
 1325144080000

Unit Price

31
JET, PILOT
JET, PILOT (45)

09492-45016-000   0949245016000

0949245016000

Unit Price

32
PLUG,NEEDLE JET<br />PLUG
PLUG, NEEDLE JET
PLUG

13357-44080-000   1335744080000

1335744080000

Unit Price

33
JET, NEEDLE (P-9)

09494-00375-000   0949400375000

0949400375000
Not available
34
WASHER

13332-44080-000  

13382-03110-000
 1333244080000

Unit Price

35
.JET, MAIN (120)

09491-24005-000   0949124005000

0949124005000
Not available
36
PLUG, DRAIN
PLUG, DRAIN

13247-44080-000   1324744080000

1324744080000

Unit Price

37
GASKET
GASKET

13246-44080-000   1324644080000

1324644080000

Unit Price

38
PLATE,NEEDLE VALVE FITING<br />PLATE
PLATE, NEEDLE VALVE FITING
PLATE

13373-11400-000   1337311400000

1337311400000

Unit Price

39
SCREW

02112-04068-000  

02112-0406B-000
 0211204068000

Unit Price

40
FLOAT
FLOTE

13250-44080-000   1325044080000

1325044080000

Unit Price

41
PIN,FLOAT<br />PIN
PIN, FLOAT
PIN

13254-92311-000   1325492311000

1325492311000

Unit Price

42
.NEEDLE VALVE ASSY

13370-11400-000   1337011400000

1337011400000
Not available
43
RING
RING

13387-47010-000   1338747010000

1338747010000

Unit Price

44
CLIP<br />E RING
CLIP
E RING

13394-10010-000   1339410010000

1339410010000

Unit Price

45
WASHER, JET NEEDLE
GASKET

13382-47010-000   1338247010000

1338247010000

Unit Price

46
SPRING,NEEDLE JET<br />SPRING
SPRING, NEEDLE JET
SPRING

13388-47010-000   1338847010000

1338847010000

Unit Price

47
NEEDLE, JET

13383-44410-000   1338344410000

1338344410000
Not available
48
.FILTER

13376-65010-000   1337665010000

1337665010000
Not available
49
O RING, NEEDLE VALVE SEAT

13374-44080-000  

13374-35C00-000
 1337444080000

Unit Price

50
.SCREW

02112-05108-000   0211205108000

0211205108000
Not available
51
SCREW, INTAKE PORT

02112-05088-000   0211205088000

0211205088000
Not available
52
.SCREW

13605-45410-000   1360545410000

1360545410000
Not available
53
JET, PILOT AIR

09493-27001-000   0949327001000

0949327001000

Unit Price

54
RING

13387-44200-000   1338744200000

1338744200000
Not available
55
SPRING

13573-44200-000   1357344200000

1357344200000
Not available
56
RING

13387-44210-000   1338744210000

1338744210000
Not available
57
FLANGE ASSY

13210-44400-000   1321044400000

1321044400000
Not available
58
SHAFT, STARTER

13410-11400-000   1341011400000

1341011400000
Not available
59
SCREW

02112-06128-000  

02112-06127-000
 0211206128000

Unit Price

60
DISCONTINUE
SCREW

13605-47070-000   1360547070000

1360547070000
Not available
61
LEVER
LEVER

13422-44080-000   1342244080000

1342244080000
Not available
62
.HOSE

13687-18656-000   1368718656000

1368718656000
Not available
63
SCREW

02112-05128-000  

02112-05127-000
 0211205128000

Unit Price

64
SCREW, INTAKE PORT

02112-05088-000   0211205088000

0211205088000
Not available
65
WASHER, LOCK

08321-21058-000  

08321-0105A-000
 0832121058000

Unit Price

66
SPRING, THROTTLE SCREW

13271-44220-000  

13268-37420-000
 1327144220000

Unit Price

67
BRACKET

13621-44210-000   1362144210000

1362144210000
Not available
68
CAP

13681-16600-000  

13681-16601-000
 1368116600000

Unit Price

69
NIPPLE

13685-11400-000   1368511400000

1368511400000
Not available
70
DISCONTINUE
ADJUSTER

13267-47070-000   1326747070000

1326747070000
Not available
71
HOSE

13687-44400-000   1368744400000

1368744400000
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CARBURETOR (MODEL Z) of your Suzuki of GS. Let us know if you have any questions.
