Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

TRANSMISSION (MODEL K6 / K7) REFER TO FIG.22A(D- 6) FOR MODEL K8/K9/L0

TRANSMISSION (MODEL K8 / K9 / L0) FOR SUZUKI QUADRACER 450 2008

GEAR SHIFTING ASSY (MODEL K6 / K7) REFER TO FIG.23A(D-10) FOR MODEL K8/K9/L0

Item numbers
TRANSMISSION (MODEL K8/K9/L0) Suzuki QUAD 450 QUADRACER 2008 LT-R450K8(E19)
1
2
3
5
6
7
7
8
9
10
11
12
13
14
15
16
17
18
19
20
20
21
22
23
24
25
26
27
28
28
29
30
30
30
31
32
33
34
35
36
37
38
39
40
41
1
SHAFT, COUNTER
SHAFT, COUNTER (NT:13)

24120-45G10-000   2412045G10000

2412045G10000

Unit Price

2
GEAR, 2ND DRIVE
GEAR, 2ND DRIVE (NT:17)

24221-45G10-000   2422145G10000

2422145G10000

Unit Price

3
GEAR, 3RD DRIVE
GEAR, 3RD DRIVE (NT:21)

24231-45G30-000   2423145G30000

2423145G30000

Unit Price

4
GEAR, 4TH DRIVE
GEAR, 4TH DRIVE (NT:21)

24241-45G10-000   2424145G10000

2424145G10000

Unit Price

5
GEAR, 5TH DRIVE
GEAR, 5TH DRIVE (NT:23)

24250-45G10-000   2425045G10000

2425045G10000

Unit Price

6
SHIM,22X28X1.0<br />WASHER, 5TH (22X28X1.0)
SHIM, 22X28X1.0
WASHER, 5TH (22X28X1.0)

09181-22139-000   0918122139000

0918122139000

Unit Price

7
SHIM, 25X32X1
WASHER, 4TH (25X32X1.0)

09181-25139-000   0918125139000

0918125139000

Unit Price

8
SHIM,25X38X1.0<br />WASHER, 4TH DRIVE, R
SHIM, 25X38X1.0
WASHER, 4TH DRIVE, R

09181-25223-000   0918125223000

0918125223000

Unit Price

9
BALL BEARING<br />BEARING, CNTR SHAFT LH
BALL BEARING
BEARING, CNTR SHAFT LH

09262-17027-000   0926217027000

0926217027000

Unit Price

10
3RD PINION CIRCLIP<br />CIRCLIP, 4TH DRIVE
3RD PINION CIRCLIP
CIRCLIP, 4TH DRIVE

09380-25003-000   0938025003000

0938025003000

Unit Price

11
BEARING
BEARING, CNTR SHAFT RH

09262-25124-000   0926225124000

0926225124000

Unit Price

12
BUSH<br />BUSH, 4TH DRIVE GEAR
BUSH
BUSH, 4TH DRIVE GEAR

24252-19F00-000   2425219F00000

2425219F00000

Unit Price

13
RING, SNAP
CIRCLIP, 2ND DRIVE

09381-24001-000   0938124001000

0938124001000

Unit Price

14
SHAFT, DRIVE
DRIVE SHAFT

24130-45G01-000   2413045G01000

2413045G01000

Unit Price

15
GEAR, 1ST DRIVEN
GEAR, 1ST DRIVEN (NT:27)

24311-45G10-000   2431145G10000

2431145G10000

Unit Price

16
GEAR, 2ND DRIVEN
GEAR, 2ND DRIVEN (NT:28)

24321-45G10-000   2432145G10000

2432145G10000

Unit Price

17
BUSH, 2ND DRIVEN GEAR
BUSH, 2ND DRIVEN

24322-35F00-000   2432235F00000

2432235F00000

Unit Price

18
GEAR SET, 3RD DRIVE DRIVEN
GEAR, 3RD DRIVEN (NT:28)

24331-45810-000   2433145810000

2433145810000

Unit Price

19
GEAR, 3RD DRIVEN
GEAR, 3RD DRIVEN (NT:28)

24331-45G30-000   2433145G30000

2433145G30000

Unit Price

20
BUSH, 3RD DRIVEN GEAR
BUSH, 3RD DRIVEN

24332-17E20-000   2433217E20000

2433217E20000

Unit Price

21
WASHER,3RD & 4TH DRIVEN<br />WASHER, 3RD DRIVEN
WASHER, 3RD & 4TH DRIVEN
WASHER, 3RD DRIVEN

24333-02F00-000   2433302F00000

2433302F00000

Unit Price

22
GEAR, 4TH DRIVEN
GEAR, 4TH DRIVEN (NT:23)

24341-45G10-000   2434145G10000

2434145G10000

Unit Price

23
GEAR, 5TH DRIVEN
GEAR, 5TH DRIVEN (NT:21)

24351-45G10-000   2435145G10000

2435145G10000

Unit Price

24
WASHER<br />WASHER, 1ST DRIVEN RH
WASHER
WASHER, 1ST DRIVEN RH

09181-20251-000   0918120251000

0918120251000

Unit Price

25
WASHER<br />WASHER, 1ST DRIVEN LH
WASHER
WASHER, 1ST DRIVEN LH

09181-22223-000   0918122223000

0918122223000

Unit Price

26
WASHER(27X36X1)<br />WASHER, 2ND DRIVEN
WASHER(27X36X1)
WASHER, 2ND DRIVEN

09160-27008-000   0916027008000

0916027008000

Unit Price

27
BEARING,25X62X17<br />BEARING, DRIVE SHAFT LH
BEARING, 25X62X17
BEARING, DRIVE SHAFT LH

09262-25125-000   0926225125000

0926225125000

Unit Price

28
SEAL,OIL(25X38X6)<br />SEAL, DRIVE SHAFT OIL
SEAL, OIL(25X38X6)
SEAL, DRIVE SHAFT OIL

09283-25086-000   0928325086000

0928325086000

Unit Price

28
SEAL, OIL, 25X38X
SEAL, DRIVE SHAFT OIL

09283-25106-000   0928325106000

0928325106000

Unit Price

29
BUSH<br />BUSH, 1ST DRIVEN GEAR
BUSH
BUSH, 1ST DRIVEN GEAR

09300-22008-000   0930022008000

0930022008000

Unit Price

30
CIRCLIP
CIRCLIP, 2ND/3RD DRIVEN

09380-27006-000   0938027006000

0938027006000

Unit Price

31
BEARING
BEARING, DRIVE SHAFT RH

09262-20106-000   0926220106000

0926220106000

Unit Price

32
RETAINER, CNTR SHAFT BEARING, R
RETAINER, COUNTER SHAFT RH

24741-05G00-000   2474105G00000

2474105G00000

Unit Price

33
SCREW<br />SCREW (6X12)
SCREW
SCREW (6X12)

09126-06011-000   0912606011000

0912606011000

Unit Price

34
SPROCKET, ENGINE(14T)
SPROCKET, ENGINE (NT:14)

27511-07G00-000   2751107G00000

2751107G00000

Unit Price

35
PLATE, ENGINE SPROCKET
PLATE, SPROCKET

27512-07G00-000   2751207G00000

2751207G00000

Unit Price

36
CHAIN(RK520SMOZ10S, 96L)
CHAIN ASSY (RK520SM0Z10S, 96L)

27600-43B20-096   2760043B20096

2760043B20096

Unit Price

37
JOINT SET, CHAIN(RK)
JOINT SET

27620-43B20-000   2762043B20000

2762043B20000

Unit Price

38
BOLT
BOLT (6X13)

09111-06039-000   0911106039000

0911106039000

Unit Price

39
RETAINER, KICK IDLE GEAR
RETAINER, KICK IDLE

26264-45G00-000   2626445G00000

2626445G00000

Unit Price

40
SPACER(20X26X14)
SPACER (20X16X14)

09180-20059-000   0918020059000

0918020059000

Unit Price

41
SCREW

02122-0616A-000  

02122-0616B-000
 021220616A000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the TRANSMISSION (MODEL K8/K9/L0) of your Suzuki of QUADRACER. Let us know if you have any questions.

Genuine parts for Suzuki 450 QUADRACER 2008
