FUEL TANK (MODEL T / V) REFER TO FIG.17A(D-5) FOR MODEL W/X

FUEL TANK (MODEL W / X) FOR SUZUKI JR 50 1997

FAIRING

Item numbers

TANK, FUEL (YELLOW)

44110-04420-25Y 441100442025Y

Not available

EMBLEM SET

68120-09A20-J3P 6812009A20J3P

Not available

EMBLEM SET

68120-09A30-M2V 6812009A30M2V

Not available

DISCONTINUE
TANK CAP

44200-40811-000 4420040811000

Not available

GASKET

44248-05210-000

44248-05211-000

$10,97

Unit Price

HOSE

09352-50823-600

09352-50005-600

$11,97

Unit Price

BOLT

01500-06903-000 0150006903000

Not available

08321-0106A
LOCK WASHER

08321-01063-000

Not available

08310-0006A
NUT

08310-00063-000

Not available

MUD GUARD WASHER
WASHER

09160-06028-000 0916006028000

$2,97

Unit Price

SPACER(6.5X10X11.5)
SPACER

09180-06289-000 0918006289000

$4,97

Unit Price

CUSHION

09320-10008-000

09320-10075-000

$4,97

Unit Price

DISCONTINUE
CUSHION, UPPER

44542-04420-000 4454204420000

Not available

SPACER, 6.5X9X7.2
SPACER

09180-06260-000 0918006260000

$5,97

Unit Price

MUD GUARD WASHER
WASHER

09160-06028-000 0916006028000

$2,97

Unit Price

BOLT

01500-06163-000

01500-0616A-000

$2,97

Unit Price

COCK ASSY, FUEL

44300-04420-000 4430004420000

$67,97

Unit Price

O RING
O RING, JOINT

44348-41370-000 4434841370000

$2,97

Unit Price

O RING, LEVER

44353-41370-000 4435341370000

$6,97

Unit Price

SPRING

44357-32470-000 4435732470000

$3,97

Unit Price

SCREW

44343-41370-000 4434341370000

$3,97

Unit Price

HOSE

09352-50823-600

09352-50005-600

$11,97

Unit Price

OIL HOSE CLAMP
CLIP

09401-08401-000 0940108401000

$2,97

Unit Price

SCREW

02112-36163-000

02112-3616B-000

$4,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FUEL TANK (MODEL W/X) of your Suzuki of JR. Let us know if you have any questions.
