HEADLIGHT (MODEL K / L / M / N) REFER TO FIG.25 (F-10) FOR MODEL K/L/M/N E4,E15,E16,E17,

HEADLIGHT (SEE NOTE) FOR SUZUKI GS-E 500 1995

HEADLIGHT (MODEL P / R) REFER TO FIG.25B(F-12) FOR P9

Item numbers

HEADLAMP ASSY

35100-01D41-999 3510001D41999

Not available

RIM

35111-01D40-000 3511101D40000

Not available

LAMP UNIT

35121-01D41-000 3512101D41000

Not available

RING

35127-01D40-000 3512701D40000

Not available

RING, MOUNTING

35130-01D40-000 3513001D40000

Not available

COVER, SOCKET

35173-45000-000

35173-20A01-000

$23,97

Unit Price

SCREW

02112-05166-000

02112-0516B-000

$2,97

Unit Price

CUSHION

35415-01D40-000 3541501D40000

Not available

CUSHION

35416-01D40-000 3541601D40000

Not available

SPACER

35414-01D40-000 3541401D40000

Not available

WASHER

35413-01D40-000 3541301D40000

Not available

WASHER, LOCK

08321-01057-000

08321-0105A-000

$2,97

Unit Price

NUT

08310-00057-000 0831000057000

$3,97

Unit Price

SCREW

35151-45900-000 3515145900000

$8,97

Unit Price

NUT

35152-15611-000 3515215611000

$6,97

Unit Price

DISCONTINUE
SPRING

35154-33630-000 3515433630000

Not available

SCREW

02112-04103-000

02112-0410A-000

$2,97

Unit Price

SETTING, BULB
SETTER, BULB

35136-34400-000 3513634400000

$6,97

Unit Price

SOCKET

36118-04A00-000 3611804A00000

$16,97

Unit Price

BULB(12V, 5W)
BULB (12V60/55W)

09471-12060-000

Not available

DISCONTINUE
BULB (12V60/55W)

09471-12144-000 0947112144000

Not available

BULB (12V, 4W)

09471-12063-000

Not available

SCREW

02122-05127-000 0212205127000

$3,97

Unit Price

REFLECTOR, REFLEX FR
REFLEX REFLECTOR, FRONT SIDE

35950-14A00-000 3595014A00000

$23,97

Unit Price

NUT

08316-20053-000

08316-2005A-000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the HEADLIGHT (SEE NOTE) of your Suzuki GSE 500 of GS-E. Let us know if you have any questions.
