FAIRING (MODEL X) REFER TO FIG.35C(F-13) FOR MODEL Y

FAIRING (MODEL Y) FOR SUZUKI GS-E 500 1999

HEADLAMP HOUSING

Item numbers

DISCONTINUE
COVER, FRAME RH (BLACK)

47110-01DH0-33J 4711001DH033J

Not available

COVER, FRAME RH (ORANGE)

47110-01DH0-Y0W 4711001DH0Y0W

Not available

DISCONTINUE
COVER, FRAME RH (BLUE)

47110-01DH0-Y7E 4711001DH0Y7E

Not available

DISCONTINUE
TAPE, RH

68135-01D30-J6A 6813501D30J6A

Not available

TAPE, RH

68135-01D30-L6W 6813501D30L6W

Not available

DISCONTINUE
TAPE, RH

68135-01D30-N6K 6813501D30N6K

Not available

DISCONTINUE
PROTECTOR, RH

47119-01D00-000 4711901D00000

Not available

DISCONTINUE
COVER, FRAME LH (BLACK)

47210-01DH0-33J 4721001DH033J

Not available

COVER, FRAME LH (ORANGE)

47210-01DH0-Y0W 4721001DH0Y0W

Not available

DISCONTINUE
COVER, FRAME LH (BLUE)

47210-01DH0-Y7E 4721001DH0Y7E

Not available

TAPE, LH

68145-01D30-J6A 6814501D30J6A

Not available

TAPE, LH

68145-01D30-L6W 6814501D30L6W

Not available

DISCONTINUE
TAPE, LH

68145-01D30-N6K 6814501D30N6K

Not available

DISCONTINUE
PROTECTOR, LH

47219-01D00-000 4721901D00000

Not available

BOLT

09116-06010-000

01500-06207-000

$3,97

Unit Price

SPACER, 6.5X10X7

09180-06263-000

09180-06283-000

$3,97

Unit Price

CUSHION

09320-09016-000 0932009016000

$3,97

Unit Price

DISCONTINUE
COVER, CENTER (BLACK)

47215-01D00-33J 4721501D0033J

Not available

COVER, CENTER (ORANGE)

47215-01D00-Y0W 4721501D00Y0W

Not available

DISCONTINUE
COVER, CENTER (BLUE)

47215-01D00-Y7E 4721501D00Y7E

Not available

SCREW

03242-05123-000

03241-0512A-000

$2,97

Unit Price

WASHER

09161-05017-000 0916105017000

$5,97

Unit Price

NUT INST CENTER

09148-05004-000

09148-05013-000

$3,97

Unit Price

CUSHION(8X26X7)

09320-08018-000

09320-08513-000

$5,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FAIRING (MODEL Y) of your Suzuki GSE 500 of GS-E. Let us know if you have any questions.
