HEADLIGHT (GS500FH P2, P19, P54, GS500FM P19) REFER TO FIG. 30 (E- 6) FOR GS500H P24

HEADLIGHT (GS500H P24) FOR SUZUKI GS-E 500 2007

HEADLIGHT (GS500FH P24)

Item numbers
HEADLIGHT (GS500H P24) Suzuki MOTO 500 GS-E 2007 GS500HUK7(P02)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
HEADLAMP ASM
HEADLAMP ASSY

35100-01D80-999   3510001D80999

3510001D80999

Unit Price

2
RIM, HEADLAMP
RIM

35111-0BE00-000   351110BE00000

351110BE00000

Unit Price

3
DISCONTINUE
LAMP UNIT

35121-0BE00-000   351210BE00000

351210BE00000
Not available
4
COVER, SOCKET

35173-0BE00-000   351730BE00000

351730BE00000
Not available
5
SCREW

35181-0BE00-000   351810BE00000

351810BE00000
Not available
6
WASHER

D8321-0104B-000   D83210104B000

D83210104B000
Not available
7
NUT

D8310-0004B-000   D83100004B000

D83100004B000
Not available
8
SCREW, ADJUSTING

35151-0BE00-000   351510BE00000

351510BE00000
Not available
9
NUT

35152-0BE00-000   351520BE00000

351520BE00000
Not available
10
SPRING

35154-0BE00-000   351540BE00000

351540BE00000
Not available
11
SPRING

35174-0BE00-000   351740BE00000

351740BE00000
Not available
12
BULB(12V, 5W)
BULB (12V60/55W)

09471-12060-000  

0947112060000
Not available
13
SCREW (L:12)

D2116-0512B-000   D21160512B000

D21160512B000
Not available
14
REFLEX REFLECTOR ASSY, FR SIDE

35950-14A10-000  

35950-14A11-000
 3595014A10000

Unit Price

15
BOLT

09119-05023-000   0911905023000

0911905023000

Unit Price

16
WASHER

D8322-0105B-000  

08322-0105B-000
 D83220105B000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the HEADLIGHT (GS500H P24) of your Suzuki GSE 500 of GS-E. Let us know if you have any questions.
