CAM SHAFT - VALVE FOR SUZUKI QUADMASTER 500 2000

TIMING

CAM SHAFT - VALVE Suzuki QUAD 500 QUADMASTER 2000 LT-F500FY(E24)
1
DISCONTINUE

12710-44D01-000  

1271044D01000
Not available
2
SPROCKET, CAMSHAFT
SPROCKET

12741-09F00-000   1274109F00000

1274109F00000

Unit Price

3
KNOCK PIN, SPROCKET
PIN

09261-05005-000   0926105005000

0926105005000

Unit Price

4
WASHER, SPROCKET
WASHER

12747-44B00-000   1274744B00000

1274744B00000

Unit Price

5
BOLT, SPROCKET
BOLT (6X10.5)

09111-06032-000   0911106032000

0911106032000

Unit Price

6
C-RING, CAM SHAFT
C RING

09390-22002-000   0939022002000

0939022002000

Unit Price

7
ARM, VALVE ROCKER INTAKE

12840-15F00-000  

12840-15G00-000
 1284015F00000

Unit Price

8
SCREW, TAPPET ADJUSTING
SCREW

12842-17C50-000   1284217C50000

1284217C50000

Unit Price

9
NUT,TAPPET ADJUSTING<br />NUT
NUT, TAPPET ADJUSTING
NUT

12843-27A00-000   1284327A00000

1284327A00000

Unit Price

10
ARM, VALVE ROCKER EXHAUST
ARM, VALVE ROCKER, EX

12850-14D50-000   1285014D50000

1285014D50000

Unit Price

11
SCREW, TAPPET ADJUSTING
SCREW

12842-17C50-000   1284217C50000

1284217C50000

Unit Price

12
NUT,TAPPET ADJUSTING<br />NUT
NUT, TAPPET ADJUSTING
NUT

12843-27A00-000   1284327A00000

1284327A00000

Unit Price

13
SHAFT, VALVE ROCKER ARM INTAKE
SHAFT, ROCKER ARM, IN

12861-14D50-000   1286114D50000

1286114D50000

Unit Price

14
SHAFT, VALVE ROCKER ARM EXHAUST
SHAFT, ROCKER ARM, EX

12871-14D50-000   1287114D50000

1287114D50000

Unit Price

15
WASHER, V LKR ARM SFT
WASHER (12.7X18.1X0.2)

09164-12018-000   0916412018000

0916412018000

Unit Price

16
09248-14011<br />PLUG, SHAFT
09248-14011
PLUG, SHAFT

09248-14005-000  

0924814005000
Not available
17
GASKET,13.8X18.8X0.4<br />GASKET
GASKET, 13.8X18.8X0.4
GASKET

09168-14002-000   0916814002000

0916814002000

Unit Price

18
VALVE, INTAKE

12911-14D01-000  

12911-14D10-000
 1291114D01000

Unit Price

19
VALVE, EXHAUST

12912-14D01-000   1291214D01000

1291214D01000

Unit Price

20
SPRING SET, VALVE
SPRING SET, VALVE

12920-06B00-000   1292006B00000

1292006B00000

Unit Price

21
RETAINER,VALVE SPRING<br />RETAINER, SPRING
RETAINER, VALVE SPRING
RETAINER, SPRING

12931-27A01-000   1293127A01000

1293127A01000

Unit Price

22
COTTER, VALVE
COTTER, VALVE

12932-27A00-000   1293227A00000

1293227A00000

Unit Price

23
SEAT,VALVE SPRING<br />SEAT, SPRING
SEAT, VALVE SPRING
SEAT, SPRING

12933-81400-000   1293381400000

1293381400000

Unit Price

24
OIL SEAL<br />OIL SEAL (5X10X8.7)
OIL SEAL
OIL SEAL (5X10X8.7)

09289-05011-000   0928905011000

0928905011000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
