WIRING HARNESS

RIGHT SWITCH FOR SUZUKI DR 650 1990

CYLINDER HEAD

Item numbers
RIGHT SWITCH Suzuki MOTO 650 DR 1990 DR650R L/DR650RU L
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
16
17
18
19
1
GRIP, THROTTLE

57110-12D00-000   5711012D00000

5711012D00000

Unit Price

2
CASE ASSY, THROTTLE

57100-28B00-000  

57100-13610-000
 5710028B00000

Unit Price

3
57122-13610
.PIECE

57122-13600-000   5712213600000

5712213600000
Not available
4
COVER, THROTTLE CASE
.COVER

57129-13601-000   5712913601000

5712913601000

Unit Price

5
SCREW

02132-04105-000  

02122-04103-000
 0213204105000

Unit Price

6
SCREW

02112-05164-000  

02112-0516B-000
 0211205164000

Unit Price

7
LEVER, BRAKE
LEVER

57421-13001-000   5742113001000

5742113001000

Unit Price

8
BOLT, BRAKE LEVER PIVOT
BOLT

57431-05D00-000   5743105D00000

5743105D00000

Unit Price

9
NUT

08319-21068-000  

08319-2106A-000
 0831921068000

Unit Price

10
SWITCH ASSY, HANDLE RH

37200-14A00-000   3720014A00000

3720014A00000
Not available
11
.SCREW
.SCREW

09125-05066-000   0912505066000

0912505066000

Unit Price

12
SWITCH ASSY, STOP

57460-17C00-000  

57460-14J02-000
 5746017C00000

Unit Price

13
SCREW,WITH WASHER(4X12)<br />.SCREW
SCREW, WITH WASHER(4X12)
.SCREW

57465-17C00-000   5746517C00000

5746517C00000

Unit Price

14
COVER, KNUCKLE, R

57341-05D00-30H  

57341-05D10-30H
 5734105D0030H

Unit Price

14
COVER, KNUCKLE RH (WHITE)

57341-05D00-14L   5734105D0014L

5734105D0014L
Not available
15
SCREW

09125-05042-000  

02142-0510A-000
 0912505042000

Unit Price

16
WASHER

09160-05017-000  

09160-05043-000
 0916005017000

Unit Price

17
WASHER

09160-06042-000   0916006042000

0916006042000
Not available
18
NUT

08319-21068-000  

08319-2106A-000
 0831921068000

Unit Price

19
FUEL HOSE CLAMP<br />BAND
FUEL HOSE CLAMP
BAND

09407-12402-000   0940712402000

0940712402000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the RIGHT SWITCH of your Suzuki DR 650 DJEBEL of DR. Let us know if you have any questions.

Genuine parts for Suzuki 650 DR 1990

BODY/FRAME ELECTRICAL ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 650 DR 1990

Select your Suzuki 1990 model

650 DR 1990 DR650R L/DR650RU L

DR 650 DJEBEL

Suzuki DR

Displacement: 650 cc
Year: 1990
Model code DR650R L / DR650RU L
