OIL COOLER

FUEL EVAP SYSTEM (E18,E39) FOR SUZUKI DR 650 1991

CLUTCH

Item numbers

PIPE, 2ND AIR

18420-12D00-000 1842012D00000

Not available

GASKET

18441-12D00-000 1844112D00000

Not available

GASKET (NA)

18441-12D10-000 1844112D10000

Not available

BOLT, STUD

01421-06165-000

01421-0616A-000

$3,97

Unit Price

NUT 6MM

08316-16064-000

08319-31067-000

$3,97

Unit Price

BOLT

07120-06125-000

07120-0612B-000

$4,97

Unit Price

WASHER

09160-06069-000

09160-06052-000

$3,97

Unit Price

CLIP

09401-13408-000

09401-13417-000

$3,97

Unit Price

CLIP

09401-16402-000

09401-16403-000

$3,97

Unit Price

HOSE ASSY

18440-12D00-000 1844012D00000

Not available

HOSE, 2ND AIR

18440-14D00-000 1844014D00000

Not available

CLIP

13828-00020-000 1382800020000

Not available

VALVE ASSY, 2ND AIR REED

18450-12D00-000 1845012D00000

Not available

BOLT

07120-06205-000

07120-0620B-000

$4,97

Unit Price

CLIP

09401-23403-000 0940123403000

Not available

CLIP

09401-15404-000 0940115404000

$3,97

Unit Price

HOSE, 2ND AIR NO.4

18432-14A10-000 1843214A10000

Not available

PIPE, 2ND AIR NO.2

18431-12D00-000 1843112D00000

Not available

HOSE, 2ND AIR NO.2

18432-12D00-000 1843212D00000

Not available

15A

HOSE, 2ND AIR NO.2

18431-12D10-000 1843112D10000

Not available

15B

UNION, 2ND AIR HOSE

18432-14D00-000 1843214D00000

Not available

HOSE, 2ND AIR NO.3

09359-40701-250 0935940701250

Not available

BAND, WIRING HARNESS
CLAMP

09407-14403-000 0940714403000

$3,97

Unit Price

CLAMP, WIRING HARNESS
CLAMP (L:165)

09407-18402-000 0940718402000

$3,97

Unit Price

BRACKET, OIL COOLER UPPER

16620-12D10-000 1662012D10000

Not available

PLUG

07110-08125-000

07130-08123-000

$4,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FUEL EVAP SYSTEM (E18,E39) of your Suzuki DR 650 RS of DR. Let us know if you have any questions.
