Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

FRAME FOR SUZUKI DR 650 2007

FOOTREST

Item numbers
FRAME Suzuki MOTO 650 DR 2007 DR650SEK7(E3/E28)
1
1
1
1
2
2
3
4
5
5
6
7
8
9
10
11
12
13
13
14
14
15
15
16
16
16
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
1
FRAME (GRAY)

41100-32E20-YPT   4110032E20YPT

4110032E20YPT
Not available
1
FRAME (GRAY)

41100-32E20-YU8   4110032E20YU8

4110032E20YU8
Not available
1
DISCONTINUE
FRAME (GRAY)

41100-32E30-YPT   4110032E30YPT

4110032E30YPT
Not available
1
DISCONTINUE
FRAME (GRAY)

41100-32E30-YU8   4110032E30YU8

4110032E30YU8
Not available
2
PLATE, ENG MTG FR
PLATE, FRONT RH

41911-32E00-000   4191132E00000

4191132E00000

Unit Price

3
BOLT(8X100)
BOLT, FRONT

09103-08139-000   0910308139000

0910308139000

Unit Price

4
NUT
NUT

08319-3108A-000   083193108A000

083193108A000

Unit Price

5
PLATE, ENG MTG UPR
PLATE, UPPER

41991-32E00-000   4199132E00000

4199132E00000

Unit Price

6
BOLT,8X55<br />BOLT, UPPER
BOLT, 8X55
BOLT, UPPER

09103-08339-000   0910308339000

0910308339000

Unit Price

7
NUT
NUT

08319-3108A-000   083193108A000

083193108A000

Unit Price

8
PLATE, ENG MTG RR, R
PLATE, REAR RH (BLACK)

41930-32E00-019   4193032E00019

4193032E00019

Unit Price

9
BOLT<br />BOLT, REAR
BOLT
BOLT, REAR

01550-0820B-000   015500820B000

015500820B000

Unit Price

10
PLUG
CAP

09250-20012-000   0925020012000

0925020012000

Unit Price

11
BRACKET, STOP SWITCH

43251-32E00-000   4325132E00000

4325132E00000

Unit Price

12
BOLT
BOLT

02162-0616B-000   021620616B000

021620616B000

Unit Price

13
BOLT 8X38<br />BOLT
BOLT 8X38
BOLT

09103-08178-000   0910308178000

0910308178000

Unit Price

14
ROLLER, CHAIN CONTROL UPR
ROLLER, CHAIN

43911-13E00-000   4391113E00000

4391113E00000

Unit Price

15
SPACER 8X6X12X25.5

09180-08119-000  

09180-08156-000
 0918008119000

Unit Price

16
WASHER THRUST<br />WASHER
WASHER THRUST
WASHER

08211-08201-000   0821108201000

0821108201000

Unit Price

17
09800-21084
TOOL ASSY

09800-21034-000  

0980021034000
Not available
18
SPANNER, BOX(16)
BOX SPANNER 16

09816-00100-000   0981600100000

0981600100000

Unit Price

19
HOLDER, TOOL

41550-32E00-000   4155032E00000

4155032E00000

Unit Price

20
CAP, HOLDER
CAP

41552-37210-000   4155237210000

4155237210000

Unit Price

21
BOLT 6X16 W/PL-WASHE
BOLT

09116-06006-000   0911606006000

0911606006000

Unit Price

22
BRACKET, TOOL HOLDER

47440-32E00-000   4744032E00000

4744032E00000

Unit Price

23
BOLT
BOLT

01550-0616B-000   015500616B000

015500616B000

Unit Price

24
HOLDER, BATTERY

41540-32E00-000   4154032E00000

4154032E00000

Unit Price

25
BOLT<br />BOLT, UPPER
BOLT
BOLT, UPPER

09116-06167-000   0911606167000

0911606167000

Unit Price

26
WASHER
SPACER

09169-06065-000   0916906065000

0916906065000

Unit Price

27
CUSHION (8.5X20X8)
CUSHION (8.5X20X8)

09320-08021-000  

09320-08510-000
 0932008021000

Unit Price

28
BOLT(6X16)
BOLT, SIDE

09116-06213-000   0911606213000

0911606213000

Unit Price

29
FENDER FRONT SPACER<br />SPACER
FENDER FRONT SPACER
SPACER

09180-06038-000   0918006038000

0918006038000

Unit Price

30
CUSHION (8.5X20X8)
CUSHION (8.5X20X8)

09320-08021-000  

09320-08510-000
 0932008021000

Unit Price

31
PLATE, BATTERY FITING
PLATE, FITTING

41561-32E00-000   4156132E00000

4156132E00000

Unit Price

32
BOLT
BOLT

01550-0610B-000   015500610B000

015500610B000

Unit Price

33
PLUG, FRAME PIVOR, R
PLUG, FRAME PIVOT RH

43585-32E00-000   4358532E00000

4358532E00000

Unit Price

34
PLUG, FRAME PIVOR, L
PLUG, FRAME PIVOT LH

43595-32E00-000   4359532E00000

4359532E00000

Unit Price

35
PLUG, FRAME BOSS

43586-32E00-000   4358632E00000

4358632E00000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME of your Suzuki of DR. Let us know if you have any questions.

Genuine parts for Suzuki 650 DR 2007

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 650 DR 2007

Select your Suzuki 2007 model

650 DR 2007 DR650SEK7(E3/E28)
650 DR 2007 DR650SEK7(E3/E28)
650 DR 2007 DR650SEK7(E3/E28)
650 DR 2007 DR650SEK7(E3/E28)

Suzuki DR

Displacement: 650 cc
Year: 2007
Model code DR650SEK7(E3 / E28)
