CYLINDER

CRACKCASE COVER FOR SUZUKI GLADIUS 650 2012

CRACKCASE COVER

Item numbers
CRACKCASE COVER Suzuki MOTO 650 GLADIUS 2012 SFV650AL2(E03,E28,E33)
1
2
3
3
3
3
3
3
3
3
3
4
4
4
5
5
5
5
6
6
7
7
8
9
10
11
12
13
14
14
15
15
16
16
17
17
18
18
18
19
19
19
20
21
22
23
24
24
25
25
26
27
28
29
30
31
31
32
33
34
35
1
CRANKCASE SET

11301-27850-000  

11301-27871-000
 1130127850000

Unit Price

2
PIN, CRANKCASE
.PIN (8.4X11X20)

09206-11007-000   0920611007000

0920611007000

Unit Price

3
.BOLT
.BOLT

01547-0650A-000   015470650A000

015470650A000

Unit Price

4
.BOLT

07120-0855A-000   071200855A000

071200855A000

Unit Price

5
.BOLT
.BOLT

07120-0880A-000   071200880A000

071200880A000

Unit Price

6
JET,OIL<br />JET AIR (14)
JET, OIL
JET AIR (14)

09493-28010-000   0949328010000

0949328010000

Unit Price

7
O RING<br />O RING (D:1.2,ID:4)
O RING
O RING (D:1.2, ID:4)

09280-04004-000   0928004004000

0928004004000

Unit Price

8
JET, OIL GALLERY(18)
JET, OIL GALY (18)

09493-36004-000   0949336004000

0949336004000

Unit Price

9
O RING<br />O RING (D:1.2,ID:4)
O RING
O RING (D:1.2, ID:4)

09280-04004-000   0928004004000

0928004004000

Unit Price

10
O RING (D:1.9,ID:12.6)
O RING (D:1.9, ID:12.6)

09280-12009-000   0928012009000

0928012009000

Unit Price

11
O RING (D:2.4,ID:15.8)
O RING (D:2.4, ID:15.8)

09280-15007-000   0928015007000

0928015007000
Not available
12
PLUG, OIL DRAIN
PLUG (12X20)

09247-12011-000   0924712011000

0924712011000

Unit Price

13
GASKET OIL GALLERY<br />GASKET (12.1X16.2X3.7)
GASKET OIL GALLERY
GASKET (12.1X16.2X3.7)

09168-12002-000   0916812002000

0916812002000
Not available
14
PLATE, PISTON COOLING JET

16438-19F00-000   1643819F00000

1643819F00000

Unit Price

15
BOLT (6X12)
BOLT (6X12)

09106-06075-000   0910606075000

0910606075000

Unit Price

16
O RING<br />O RING (D:1.2,ID:4)
O RING
O RING (D:1.2, ID:4)

09280-04004-000   0928004004000

0928004004000

Unit Price

17
JET (13)
JET (13)

09493-26007-000   0949326007000

0949326007000

Unit Price

18
BOLT
BOLT

01550-0812A-000  

01550-0812B-000
 015500812A000

Unit Price

19
GASKET (8.2X14X1)
GASKET (8.2X14X1)

09168-08016-000   0916808016000

0916808016000

Unit Price

20
PLUG,OIL<br />PLUG (16X8)
PLUG, OIL
PLUG (16X8)

09248-16012-000   0924816012000

0924816012000

Unit Price

21
GASKET OIL GALLERY<br />GASKET (16X22X2)
GASKET OIL GALLERY
GASKET (16X22X2)

09168-16002-000   0916816002000

0916816002000

Unit Price

22
PLATE, OIL SEPARATOR
PLATE, OIL SEPARATOR

11323-19F00-000   1132319F00000

1132319F00000

Unit Price

23
BOLT

01547-0612A-000   015470612A000

015470612A000

Unit Price

24
BOLT

01547-0610A-000   015470610A000

015470610A000

Unit Price

25
GASKET<br />GASKET (5.8X13X1.2)
GASKET
GASKET (5.8X13X1.2)

09168-06023-000   0916806023000

0916806023000
Not available
26
PLUG
PLUG (12X10)

09247-12006-000   0924712006000

0924712006000

Unit Price

27
WASHER<br />GASKET (12X17X1)
WASHER
GASKET (12X17X1)

09168-12017-000   0916812017000

0916812017000

Unit Price

28
BOLT<br />BOLT (10X215)
BOLT
BOLT (10X215)

09103-10041-A05   0910310041A05

0910310041A05

Unit Price

29
BOLT,L:205<br />BOLT (10X205)
BOLT, L:205
BOLT (10X205)

09103-10145-000   0910310145000

0910310145000

Unit Price

30
BOLT (12X300)

09103-12016-000   0910312016000

0910312016000

Unit Price

31
NUT

09159-10111-000   0915910111000

0915910111000

Unit Price

32
NUT

09159-12054-000   0915912054000

0915912054000

Unit Price

33
SWITCH ASSY,OIL PRESSURE
SWITCH ASSY, OIL PRESSURE

37820-33D10-000  

37820-33D11-000
 3782033D10000

Unit Price

34
.BOLT, OIL PRESSURE SWITCH

37822-33D00-000   3782233D00000

3782233D00000

Unit Price

35
CLAMP(L:65)
CLAMP(L:65)

09404-06429-000  

09404-06039-000
 0940406429000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
