Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

HANDLEBAR (WITHOUT COWLING) REFER TO FIG.49(H-13) FOR WITH COWLING

HANDLEBAR (WITH COWLING) FOR SUZUKI SV 650 2005

LEVERS - HANDGRIPS (MODEL K3 / K4 / K5 / K6) REFER TO FIG.50A(H-15) FOR MODEL K7

Item numbers
HANDLEBAR (WITH COWLING) Suzuki MOTO 650 SV 2005 SV650K5/SK5(E3/E28)
1
2
3
4
5
6
7
8
9
10
11
11
12
12
13
14
15
16
17
18
18
19
20
1
HANDLEBAR, R
HANDLEBAR, RH

56111-17G00-000   5611117G00000

5611117G00000

Unit Price

2
HANDLEBAR, L
HANDLEBAR, LH

56151-17G00-000   5615117G00000

5615117G00000

Unit Price

3
BOLT, HANDLEBAR
BOLT

56123-35F00-000   5612335F00000

5612335F00000

Unit Price

4
BALANCER SET, HANDLEBAR

56200-16830-000  

56200-16834-000
 5620016830000

Unit Price

5
SCREW

02122-06953-000  

02122-0695B-000
 0212206953000

Unit Price

6
DISCONTINUE
EXPANDER, OUTER

56272-23F00-000  

5627223F00000
Not available
7
SPACER,EXPANDER<br />SPACER
SPACER, EXPANDER
SPACER

56276-17D00-000   5627617D00000

5627617D00000

Unit Price

8
WASHER,6.5X16X1.6<br />WASHER
WASHER, 6.5X16X1.6
WASHER

09160-06130-000   0916006130000

0916006130000

Unit Price

9
EXPANDER, HANDLE BALANCER

56272-10G00-000  

56272-10G01-000
 5627210G00000

Unit Price

10
NUT, HANDLE BALANCER

56273-10G00-000  

56273-10G10-000
 5627310G00000

Unit Price

11
MIRROR ASSY, RR VIEW, R

56500-16G00-000  

56500-16G10-000
 5650016G00000

Unit Price

12
MIRROR ASSY, RR VIEW, L

56600-16G00-000  

56600-16G10-000
 5660016G00000

Unit Price

13
CUSHION,REAR VIEW MI<br />CUSHION
CUSHION, REAR VIEW MI
CUSHION

94576-24F00-000   9457624F00000

9457624F00000

Unit Price

14
BOLT

07130-06163-000  

07130-0616B-000
 0713006163000

Unit Price

15
CAP
CAP

09250-05009-000   0925005009000

0925005009000

Unit Price

16
CABLE ASSY, CLUTCH

58200-17G10-000   5820017G10000

5820017G10000

Unit Price

17
CABLE ASSY, THROTTLE

58300-16G10-000  

58300-16G11-000
 5830016G10000

Unit Price

18
GUIDE, CABLE L
GUIDE, CABLE LH

58621-16GC0-000   5862116GC0000

5862116GC0000

Unit Price

18
DISCONTINUE
GUIDE, CABLE LH

58621-16GA0-000   5862116GA0000

5862116GA0000
Not available
19
BOLT

01550-06123-000  

01550-0612B-000
 0155006123000

Unit Price

20
GUIDE, THROTTLE CABLE

58621-16GB0-000   5862116GB0000

5862116GB0000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
