Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

CARRIER

FAIRING FOR SUZUKI V-STROM 650 2012

BATTERY BOX - TOOLS

Item numbers
FAIRING Suzuki MOTO 650 V-STROM 2012 DL650AUE L2 (E21)
1
1
1
2
2
2
3
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
1
COVER, FRAME, R(ORANGE

47111-11J01-YUK  

47111-11J02-YUK
 4711111J01YUK

Unit Price

1
COVER, FRAME, R(BLACK)

47111-11J01-YVB  

47111-11J02-YVB
 4711111J01YVB

Unit Price

1
DISCONTINUE
COVER, FRAME RH (WHITE)

47111-11J01-YPA  

4711111J01YPA
Not available
2
COVER, FRAME, L(ORANGE)

47211-11J01-YUK  

47211-11J02-YUK
 4721111J01YUK

Unit Price

2
COVER, FRAME, L(BLACK)

47211-11J01-YVB  

47211-11J02-YVB
 4721111J01YVB

Unit Price

2
DISCONTINUE
COVER, FRAME LH (WHITE)

47211-11J01-YPA  

4721111J01YPA
Not available
3
COVER, FRAME SIDE, R
COVER, FRAME SIDE RH

47411-11J00-000   4741111J00000

4741111J00000

Unit Price

4
COVER, FRAME SIDE, L
COVER, FRAME SIDE LH

47511-11J00-000   4751111J00000

4751111J00000

Unit Price

5
CUSHION(10X10X1)
CUSHION, FRAME COVER

63115-37H00-000   6311537H00000

6311537H00000

Unit Price

6
CUSHION
CUSHION, FRAME COVER

94423-10G00-000   9442310G00000

9442310G00000

Unit Price

7
BOLT
BOLT (5X13)

09139-05074-000   0913905074000

0913905074000

Unit Price

8
BOLT (6X20)

09139-06179-000   0913906179000

0913906179000

Unit Price

9
NUT

09148-05052-000   0914805052000

0914805052000

Unit Price

10
CUSHION(8X26X7)
CUSHION(8X26X7)

09320-08028-000  

09320-08514-000
 0932008028000

Unit Price

11
CUSHION
CUSHION

09320-09016-000   0932009016000

0932009016000

Unit Price

12
CUSHION

09320-20010-000  

09320-20011-000
 0932020010000

Unit Price

13
CENTER STAND STOP<br />CUSHION
CENTER STAND STOP
CUSHION

09321-10001-000   0932110001000

0932110001000

Unit Price

14
CLIP (BLACK)
CLIP (BLACK)

09409-06314-5PK   09409063145PK

09409063145PK

Unit Price

15
SCREW
SCREW

03541-0416A-000   035410416A000

035410416A000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FAIRING of your Suzuki V-STROM 650 of V-STROM. Let us know if you have any questions.

Genuine parts for Suzuki 650 V-STROM 2012

BODY/FRAME ELECTRICAL ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 650 V-STROM 2012

Select your Suzuki 2012 model

650 V-STROM 2012 DL650AUE L2 (E21)

V-STROM 650

Suzuki V-STROM

Displacement: 650 cc
Year: 2012
Model code DL650AUE L2 (E21)
