Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

FOOTREST

LOWER FAIRING (MODEL K6) FOR SUZUKI BURGMAN 650 2007

LOWER FAIRING (MODEL K7) REFER TO FIG.58B(I-15) FOR MODEL K8

Item numbers
LOWER FAIRING (MODEL K6) Suzuki SCOOTER 650 BURGMAN 2007 AN650K7(E2)
1
1
1
1
2
3
3
3
3
4
5
6
7
7
8
8
9
9
9
1
SHIELD, LEG SIDE, R
SHIELD, LEG SIDE RH (GRAY)

48171-10G00-YHF   4817110G00YHF

4817110G00YHF

Unit Price

1
SHIELD, LEG SIDE, R
SHIELD, LEG SIDE RH (GRAY)

48171-10G00-YHG   4817110G00YHG

4817110G00YHG

Unit Price

1
DISCONTINUE
SHIELD, LEG SIDE RH (WHITE)

48171-10G00-YC3   4817110G00YC3

4817110G00YC3
Not available
1
DISCONTINUE
SHIELD, LEG SIDE RH (BLUE)

48171-10G00-YKZ   4817110G00YKZ

4817110G00YKZ
Not available
2
CUSHION
CUSHION, RH

48172-10G00-000   4817210G00000

4817210G00000

Unit Price

3
SHIELD, LEG SIDE, L
SHIELD, LEG SIDE LH (GRAY)

48181-10G20-YHF   4818110G20YHF

4818110G20YHF

Unit Price

3
SHIELD, LEG SIDE, L
SHIELD, LEG SIDE LH (GRAY)

48181-10G20-YHG   4818110G20YHG

4818110G20YHG

Unit Price

3
SHIELD, LEG SIDE, L
SHIELD, LEG SIDE LH (BLUE)

48181-10G20-YKZ   4818110G20YKZ

4818110G20YKZ

Unit Price

3
DISCONTINUE
SHIELD, LEG SIDE LH (WHITE)

48181-10G20-YC3   4818110G20YC3

4818110G20YC3
Not available
4
COVER, LEG SHIELD, L
COVER, LEG SHIELD LH

48183-10G00-000   4818310G00000

4818310G00000

Unit Price

5
CUSHION
CUSHION, LH

48182-10G00-000   4818210G00000

4818210G00000

Unit Price

6
CLIP

09409-08326-000   0940908326000

0940908326000

Unit Price

7
BOLT
SCREW (5X16)

09132-05053-000   0913205053000

0913205053000

Unit Price

8
NUT, STEERING<br />NUT
NUT, STEERING
NUT

09148-05038-000   0914805038000

0914805038000

Unit Price

9
CLIP (BLACK)

09409-08308-5ES   09409083085ES

09409083085ES

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the LOWER FAIRING (MODEL K6) of your Suzuki of BURGMAN. Let us know if you have any questions.
