FUEL TANK (MODEL K2 / K3)

FAIRING (MODEL W) FOR SUZUKI GSX-F 750 2003

FAIRING (MODEL X) REFER TO FIG.36B(F-13) FOR MODEL Y/K1

Item numbers
FAIRING (MODEL W) Suzuki MOTO 750 GSX-F 2003 GSX750FLK3(E2)
1
1
1
2
2
2
3
3
3
4
4
4
5
6
7
8
9
10
11
12
13
13
14
15
1
COVER, FRAME RH (GREEN)

47110-08F10-1UH   4711008F101UH

4711008F101UH
Not available
1
DISCONTINUE
COVER, FRAME RH (BLACK)

47110-08F10-33J   4711008F1033J

4711008F1033J
Not available
1
DISCONTINUE
COVER, FRAME RH (MAROON)

47110-08F10-Y4M   4711008F10Y4M

4711008F10Y4M
Not available
2
EMBLEM, RH

68131-08F10-K5T   6813108F10K5T

6813108F10K5T
Not available
2
EMBLEM, RH

68131-08F10-K5U   6813108F10K5U

6813108F10K5U
Not available
2
EMBLEM, RH

68131-08F10-K5V   6813108F10K5V

6813108F10K5V
Not available
3
COVER, FRAME LH (GREEN)

47210-08F10-1UH   4721008F101UH

4721008F101UH
Not available
3
DISCONTINUE
COVER, FRAME LH (BLACK)

47210-08F10-33J   4721008F1033J

4721008F1033J
Not available
3
DISCONTINUE
COVER, FRAME LH (MAROON)

47210-08F10-Y4M   4721008F10Y4M

4721008F10Y4M
Not available
4
DISCONTINUE
EMBLEM, LH

68141-08F10-K5T   6814108F10K5T

6814108F10K5T
Not available
4
EMBLEM, LH

68141-08F10-K5U   6814108F10K5U

6814108F10K5U
Not available
4
DISCONTINUE
EMBLEM, LH

68141-08F10-K5V   6814108F10K5V

6814108F10K5V
Not available
5
SCREW<br />SCREW, UPPER
SCREW
SCREW, UPPER

09136-06105-000   0913606105000

0913606105000

Unit Price

6
SPACER,6.5X10X9.4<br />SPACER
SPACER, 6.5X10X9.4
SPACER

09180-06286-000   0918006286000

0918006286000

Unit Price

7
CUSHION
CUSHION

09320-10045-000   0932010045000

0932010045000

Unit Price

8
CUSHION, UNDER COWLING NO.1
CUSHION, REAR

94476-38C00-000   9447638C00000

9447638C00000

Unit Price

9
CUSHION(8X26X7)
CUSHION(8X26X7)

09320-08028-000  

09320-08514-000
 0932008028000

Unit Price

10
CUSHION(8X26X7)
CUSHION(8X26X7)

09320-08018-000  

09320-08513-000
 0932008018000

Unit Price

11
SCREW

03241-15163-000  

03241-1516A-000
 0324115163000

Unit Price

12
SCREW

03241-15123-000  

03241-1512B-000
 0324115123000

Unit Price

13
NUT, STEERING<br />NUT
NUT, STEERING
NUT

09148-05038-000   0914805038000

0914805038000

Unit Price

14
CUSHION(10X30X2)
CUSHION, REAR

44894-24A00-000   4489424A00000

4489424A00000

Unit Price

15
DISCONTINUE<br />CUSHION
DISCONTINUE
CUSHION

47161-08F00-000   4716108F00000

4716108F00000
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
